Kramer VP-111K 1:1 Computer Graphics Video Line Amplifier 500MHz

ITEM #: KR-VP111K MFG #: VP-111K

  • Product Image Thumbnail 1 of 2
  • Product Image Thumbnail 2 of 2
free ship

List Price:

$300.00

Our Price:

$240.00

Availability: Typically Ships in 3-10 Days
iAvailability Description Popup


    VP-111K - Overview

    High Bandwidth - 500MHz (-3dB)

    The Kramer VP-111K is a high-performance line driver for signals exceeding UXGA. It provides controls to compensate for signal losses inherent in long cable runs.

    Perfect for:
    Dual monitor systems (local and remote).
    Presentation systems: for remote transmission and cable equalization.

    • Features:

      • High Bandwidth - 500MHz (-3dB).
      • HDTV Compatible.
      • Looping Input.
      • Selectable Input Signal Termination.
      • EQ (Peaking) Control.
      • Kr-isp® Advanced Sync Processing - Ensures compatibility with a wide range of computers (even if the sync level is too low) by restoring the sync signal waveform. Kr-isp® advanced sync processing can be enabled or disabled.
      • Compact Kramer TOOLS™ - 3 units can be rack mounted side-by-side in a 1U rack space with the recommended rack adapter.

    • Specifications:

      • INPUT
      • 1 UXGA with loop on a 15-pin HD connectors

      • OUTPUTS
      • 1 UXGA on a 15-pin HD connector

      • MAX OUTPUT LEVEL
      • 2.2Vpp

      • BANDWIDTH (-3DB)
      • 500MHz

      • DIFF. GAIN
      • 0.05%

      • DIFF. PHASE
      • 0.05°

      • K-FACTOR
      • <0.05%

        S/N RATIO
      • 75dB

      • CONTROLS
      • EQ.: 0 to 10dB @50MHz

      • COUPLING
      • DC

      • POWER CONSUMPTION
      • 5V DC, 114mA

    • Item Includes:

      • VP-111K Amp
      • Power Supply
      • Mounting Bracket

    • Warranty:

      • Limited 7 Year Warranty

    • GTIN:

      7291063029913
