Kramer VS-21HDCP-IR 2x1 DVI (HDCP) Video Switcher with IR

ITEM #: KR-VS-21HDCP-IR MFG #: VS-21HDCP-IR

Primary Image
  • Product Image Thumbnail 1 of 4
  • Product Image Thumbnail 2 of 4
  • Product Image Thumbnail 3 of 4
  • Product Image Thumbnail 4 of 4

This item is no longer available.
Ask a Markertek Expert if you need assistance finding an appropriate substitute.

(800) 522-2025Email

Items similar to the KR-VS-21HDCP-IR

VS-21HDCP-IR - Overview

The VS-21HDCP-IR is a high-quality switcher for DVI signals. It switches either of two inputs to a single output.

  • Features:

    • Max. Data Rate - 2.25Gbps.
    • HDCP Compliant.
    • HDTV Compatible.
    • EDID PassThru - Passes EDID signals between the source and display.
    • Flexible Control Options - Front panel, RS-232 (K-Router Windows-based software is included), contact closure & IR remote (included).
    • Compact MultiTOOLS - 3 units can be rack mounted side-by-side in a 1U rack space with the optional RK-13 universal rack adapter.


  • Specifications:

    • INPUTS: 2 DVI , 1.2Vpp on a DVI Molex 24-pin female connector; DDC signal 5Vpp (TTL).
    • OUTPUT: 1 DVI, 1.2Vpp on DVI Molex 24-pin female connectors; DDC signal 5Vpp (TTL).
    • BANDWIDTH: 2.25Gbps per graphic channel.
    • POWER SOURCE: 5V DC, 210mA.
    • DIMENSIONS: 14.3cm x 12.2cm x 4.36cm (5.63" x 4.8" x 1.72") W, D, H.
    • WEIGHT: 0.3kg (0.66lbs) approx.
    • ACCESSORIES: Power supply, infrared remote controller.
    • OPTIONS: RK-13 19" rack adapter.


  • GTIN:

    7291063007607
