Lightronics TL-3012 Lighting Console 12 Channels x 24 Scenes - LMX
    Questions? Ask a Markertek Expert:
    800-522-2025 Email

    Lightronics TL-3012 Lighting Console 12 Channels x 24 Scenes - LMX

    Manufacturer: Lightronics

    Item #: LGT-TL3012   •   MFG #: LGT-TL3012







    The TL3012 is a compact, portable, digital dimmer controller. It is suitable for church, stage, theater, disco, night club, live performances and other event and artistic applications.

    It provides 12 channels of LMX-128 (industry standard multiplex) control on a 3 wire cable. It can optionally provide DMX output. The TL3012 operates in a 2 scene manual mode or can provide 24 preset scenes organized in 2 banks of 12 scenes each. Twelve user defined chase patterns are always available. Scene fade rate, chase rate and chase fade rate are user controlled. Audio may also be used as a chase rate control. Other features of the TL3012 include: a master fader, momentary buttons, and blackout control. Scenes and chases stored in the unit are not lost when the unit is turned off.

    • Features

      • LED Compatible
      • 12 Channels
      • 24 Scenes
      • 12 Chases with 12 Steps each
      • Built in Microphone
      • LMX-128 Protocol
      • Optional DMX-512
      • Optional Wireless DMX (stand alone)
    • Specifications

      • Channels: 12
      • Chase: 12 Programmable, 12 Steps each
      • Operating Modes: 2 Scene Manual Mode, Preset Scene Mode, Chase Mode
      • Memory: Non Volatile - Scenes and Chases Retained when Unit Powered Off
      • Scenes: 24 Scenes, 2 Banks of 12 Scenes each
      • Control Protocol: LMX-128 (3 pin multiplex), DMX-512 Optional
      • Power Requirements: Phantom Power: 18VAC or +15VDC, 400ma, External Power: 13 - 25VAC or VDC, 400ma
      • Size: 10.25"W x 9.25"D x 2.5"H
      • Weight: 4.3 Pounds
