Neutrik NLT8MP-BAG 8-Pole Male speakON Chassis Connector Square G Size Flange

    Questions? Ask a Markertek Expert:
    800-522-2025 Email

    Neutrik NLT8MP-BAG 8-Pole Male speakON Chassis Connector Square G Size Flange

    Manufacturer: Neutrik USA Inc

    Item #: NLT8MP-BAG   •   MFG #: NLT8MP-BAG



    List Price:$16.35
    Our Price:$15.00
    Quantity Pricing

    free ship


    Availability:
    In Stock
    i
    Item is Available for immediate shipping from our warehouse.






      Neutrik NLT8MP-BAG 8-pole male chassis connector, black-chrome metal housing, solder or ¬" flat tabs

      The speakON STX Series was especially designed for heavy duty amplifier-loudspeaker applications like professional touring. The extremely rugged and durable STX Series features an all metal housing.


      • Features

        • Extremely robust metal housing designed for harsh and demanding environment
        • Ideal product for touring applications and harsh environments
        • Current rating 40 Amp continuous, 50 Amp audio signal with 50% duty cycle
        • Uses precise "Quick Lock" system
        • Mates with all currently available speakON products

      • Specifications

        • Contact Resistance: < 2 mΩ (after lifetime)
        • Dielectric Strength: 3 kVdc (peak)
        • Insulation Resistance: > 10 GΩ
        • Rated Current Per Contact: 40 A rms continuous / 50 A audiosignal, duty cycle 50 %
        • Rated Voltage: 250 V ac
        • Attention: speakON is NOT to be used as an AC mains or power supply connector!
        • Lifetime: > 5000 mating cycles
        • Wiresize: 6 mm²
        • Wiresize: 10 AWG
        • Locking Device: Quick Lock
        • Chassis Shape: square G-size flange
        • Layout: four thru holes:
        • Contact Plating: 4 µm Ag
        • Insert: Polyamide (PA 6 30 % GR)
        • Shell: Zinc diecast (ZnAl4Cu1) black chrome
        • Contacts: Spring Copper (CuSn0.2)
        • Flammability: UL 94 HB
        • Protection Class: IP 50 (mated condition)
        • Solderability: Complies with IEC 68-2-20
        • Temperature Range: -30 °C to +80 °C

      • Item Includes

        • 1x Neutrik NLT8MP-BAG 8-Pole Male speakON Chassis Connector
