Rolls PS16 Power Center for PM Series Personal Monitors

ITEM #: PS16 MFG #: PS16

Primary Image
  • Product Image Thumbnail 1 of 3
  • Product Image Thumbnail 2 of 3
  • Product Image Thumbnail 3 of 3

This item is no longer available.
Ask a Markertek Expert if you need assistance finding an appropriate substitute.

(800) 522-2025Email

Items similar to the PS16

PS16 - Overview

The Rolls PS16 supplies the DC power and distributes the Monitor signal to up to ten of the PM50s, the PM50sOB, and the PM350 units by connecting them with ordinary stereo phone cords. Although the PS16 has only 4 output jacks they can be multiplied with "Y" adapters for many more outputs. This makes a much "cleaner" installation and eliminates the need for multiple wall-warts and adapter cables etc.

  • Features:

    • Supplies power for up to ten PM50s, PM50sOB, and PM350 units
    • Directly supplies a monitor signal to the above listed units
    • Unbalanced 1/4" and transformer-balanced XLR inputs
    • External Power Supply included for low noise operation

  • Specifications:

    • Audio Input: Line Level XLR Balanced, 1/4" Unbalanced Phone (mono)
    • Power Input: 12 VAC, 700 mA
    • Output Power: 12 VDC on the Ring terminal of each OUT jack.
    • Size: 3.125" x 3.125" x 1.25"
    • Weight: 1 lb (.45 Kg)

  • Item Includes:

    • External Power Supply included

  • GTIN:

    0675889001600
