    FF 802 FS - Overview

    The RME Fireface 802 FS is a highly integrated pro audio solution for live and studio use, all within a 19" enclosure. An interface designed for users who don't want to make compromises in sound, stability and ultra-low latency operation, and who long for an unrivaled professional feature set. Once again a milestone interface from RME, including the best of the best and even a bit more. 60 channels of audio, high-end microphone preamps, reference class converters, a complete effects section and operation at up to 192 kHz are the base for many more features. Like other RME products before the Fireface 802 FS combines excellent analog circuit design with latest digital conversion technology. All balanced TRS & XLR I/Os as well as the two phones outputs offer outstanding low noise and distortion values. In best RME tradition and product philosophy converters and preamps don't produce "sound", they do not add or remove anything from the source signal, just capture it as it is. Equipped with the latest low latency A/D and D/A converter chips, all I/Os operate at up to 192 kHz and reach high dynamic range on playback - even both headphone outputs. Their high power technology delivers high volume no matter if high or low impedance phones are used. Due to its efficient jitter reduction, RME's superior SteadyClock FS guarantees state-of-the-art AD/DA conversion, even when clocking to an external clock source. Every input and output is individually switchable to these common professional studio levels: -10 dBV, +4 dBu, HiGain (equivalent to +2 dBV, +13 dBu and +19 dBu for digital full scale). All outputs can be used for ASIO Direct Monitoring (ADM) purposes

    • Features:

      • All settings can be changed in real-time
      • Buffer sizes/latencies from 48 up to 8192 samples selectable
      • 8 channels 96 kHz/24 bit Record/Playback via ADAT optical (S/MUX)
      • 4 channels 192 kHz/24 bit Record/Playback via ADAT optical (S/MUX4)
      • Clock modes slave and master
      • Automatic and intelligent master/slave clock control
      • Unsurpassed Bitclock PLL (audio synchronization) in ADAT mode
      • SteadyClock: Jitter-immune, super-stable digital clock
      • DDS technology for free setting of the sample rate
      • SyncAlign guarantees sample aligned and never swapping channels
      • SyncCheck tests and reports the synchronization status of input signals
      • TotalMix for latency-free submixes and perfect ASIO Direct Monitoring
      • TotalMix: 1800 channel mixer with 46 bit internal resolution
      • TotalMix FX: 3-band EQ, Low Cut, Reverb, Echo, Compressor, Expander, Auto Level
      • MIDI I/O with 16 channels high-speed Low-Jitter MIDI
      • 2 x Hi-power low impedance headphone output
      • DIGICheck DSP: Level meter in hardware, peak- and RMS calculation

    • Specifications:

      • Analog
      • Input: 6.3 mm TRS, electronically balanced
      • Signal to Noise ratio (SNR) @ LoGain: 116 dB (AES17), 118 dBA
      • Signal to Noise ratio (SNR) @ +4 dBu: 115 dB (AES17), 117 dBA
      • Frequency response @ 44.1 kHz, -0.1 dB: 8.9 Hz - 20.4 kHz
      • Frequency response @ 96 kHz, -0.5 dB: 4.3 Hz - 45.2 kHz
      • Frequency response @ 192 kHz, -1 dB: 3 Hz - 89 kHz
      • Filter: Short Delay Sharp, 5 / 5 / 6 samples delay
      • THD @ -1 dBFS: < -120 dB, < 0.0001 %
      • THD+N @ -1 dBFS: < -110 dB, < 0.00032 %
      • Channel separation: > 110 dB ? Maximum input level: +19 dBu
      • Input: 6.3 mm TRS jack, electronically balanced
      • Input impedance @ 1 kHz: 10 kOhm unbalanced, 10.6 kOhm balanced
      • Input sensitivity switchable between Lo Gain and +4 dBu
      • Input level for 0 dBFS @ Lo Gain: +19 dBu
      • Input level for 0 dBFS @ +4 dBu: +13 dBu
      • Variable digital gain: 0 to +12 dB
      • Minimum level for 0 dBFS: +1 dBu, -1.2 dBV

        MIDI
      • 1 x MIDI I/O via 5-pin DIN jacks
      • Galvanically isolated by optocoupled input
      • Hi-speed mode: Jitter and response time typically below 1 ms
      • Separate 128 byte FIFOs for input and output

        Digital
      • AES/EBU
        1 x XLR, transformer-balanced, galvanically isolated, according to AES3-1992
        High-sensitivity input stage (< 0.3 Vpp)
        SPDIF compatible (IEC 60958)
        Accepts Consumer and Professional format
        Lock range: 27 kHz - 200 kHz
        Jitter suppression: > 50 dB (> 1 Hz)
      • ADAT Optical
        2 x TOSLINK, format according to Alesis specification
        Standard: 2 x 8 channels 24 bit, up to 48 kHz
        Double Speed (S/MUX): 2 x 4 channels 24 bit 96 kHz
        Quad Speed (S/MUX4): 2 x 2 channels 24 bit 192 kHz
        Bitclock PLL ensures perfect synchronisation even in varispeed operation
        Lock range: 31.5 kHz - 50 kHz
        Jitter suppression: > 50 dB (> 1 Hz)
      • SPDIF optical (ADAT 1/2)
        1 x optical, according to IEC 60958
        Accepts Consumer and Professional format
        Lock range: 27 kHz - 200 kHz
        Jitter suppression: > 50 dB (> 1 Hz)
      • Digital Outputs
      • AES/EBU
        1x XLR, transformer-balanced, galvanically isolated, according to AES3-1992
        Output level Professional 4.2 Vpp, Consumer 2.4 Vpp
        Format Professional according to AES3-1992 Amendment 4
        Format Consumer (SPDIF) according to IEC 60958
        Single Wire mode, sample rate 28 kHz up to 200 kHz
      • ADAT
        2 x TOSLINK, format according to Alesis specification
        Standard: 2 x 8 channels 24 bit, up to 48 kHz
        Double Speed (S/MUX): 2 x 4 channels 24 bit 96 kHz
        Quad Speed (S/MUX4): 2 x 2 channels 24 bit 192 kHz
      • SPDIF optical (ADAT 1/2)
        Format Consumer (SPDIF) according to IEC 60958
        Sample rate 28 kHz up to 200 kHz

    • Item Includes:

      • 1x Fireface 802 FS
      • 1x Cable USB 2.0, 1.8 m (6 ft) USB-A/B
      • 1x Power cord
      • 1x Manual
      • 1x Optical cable (TOSLINK), 2 m (6.6 ft)
      • 4x Rubber feet, self adhesive

    • Warranty:

      • 6 Month Warranty

    • System Requirements

      :

      • Windows 7 or up, Intel Mac OS X (10.12 or up)
      • 1 x USB 2.0 port or USB 3.0 port
      • For USB: Computer with at least Intel Core i5 CPU
