Rupert Neve Designs Portico II Master Buss Dual Path AD Converter and Limiter

ITEM #: RUP-MASBUSSCNVTR MFG #: PORTICO II MASTER BUSS CONVERTER

Primary Image
  • Product Image Thumbnail 1 of 5
  • Product Image Thumbnail 2 of 5
  • Product Image Thumbnail 3 of 5
  • Product Image Thumbnail 4 of 5
  • Product Image Thumbnail 5 of 5
Free Shipping with $49 Minimum Order

Our Price:

$3,999.00

Availability: Ships Factory Direct, Typically in 3-10 Business Days
iAvailability Description Popup


    PORTICO II MASTER BUSS CONVERTER - Overview

    Whether you’re tracking, printing mixes, or mastering, the Master Buss Converter is a revelation in quality and functionality of A-D conversion technology. The analog drive circuitry allows the MBC’s converter to be fed by either a class-A transformerless path for maximum transparency, or by custom inter-stage audio transformers with variable Silk for a wide variety of tonal enhancements. Coupled with an astonishingly musical limiter, the MBC is always the best choice to capture your analog signals with breathtakingly three-dimensional accuracy.

    • Features:

      • 24-bit/192kHz Reference Conversion
      • Active Compound Release Analog Limiting- Push your levels further with fewer artifacts than plug-ins, and introduce clip safety for tracking or broadcast.
      • Class-A Transformerless Path- Maximizes clarity and transparency of the input signal.
      • Transformer Path with Silk / Texture- Add weight and punch with a dedicated custom inter-stage transformer before the converter.
      • Selectable Analog Drive Paths- class-A transformerless and custom transformer-coupled designs at the touch of a button.
      • Precision Clocking- Maximum accuracy with minimal jitter and phase noise.
      • Multi-Standard Connectivity- AES, S/PDIF, Toslink

    • Specifications:

      • XLR Line Input to AES3 Digital Output: (Limiter Bypassed) – ZSOURCE= 40 Ω Balanced
      • Input Impedance: 9.9 kΩ
      • Common Mode Rejection @ 1 kHz: 105 dB typical

        Transformerless Path
      • Frequency Response (20 Hz to 70 kHz): +/- 0.025 dB typical
      • THD+N @1 kHz @ -2 dBFS (10 Hz - 22 kHz BW): 0.0009% typical
      • Noise (BW 10 Hz - 22 kHz): -108 dBFS typical

        Transformer Path
      • Transformer Frequency Response (20 Hz to 70 kHz): +/- 0.1 dB typical
      • THD+N @1 kHz @ -2 dBFS (10 Hz - 22 kHz BW): 0.002% typical
      • Noise (BW 10 Hz - 22 kHz): -114 dBFS typical
      • Limiter Specifications (Transformerless Path Selected): - ZSOURCE= 40 Ω Balanced
      • Frequency Response (20 Hz to 70 kHz): +/- 0.1 dB typical
      • Noise @ 0 dB Make-Up Gain (10 Hz - 22 kHz BW): -107 dBFS typical
      • Noise @ +20 dB Make-Up Gain (10 Hz - 22 kHz BW): -97 dBFS typical

    • Item Includes:

      • 1x MBC - Master Buss Converter
      • 1x PSU Cable
      • 1x Manual

    • Warranty:

      • 1 Year Warranty

    • GTIN:

      0763854076767
