ADX2FD/B58 - Overview

The Shure ADX2FD/B58, like all ADX transmitters, sets the stage for exceptional performance, with wide tuning up to 184 MHz, interference protection, advanced rechargeability, streamlined design, and ShowLink remote control for real-time parameter adjustments right from the booth.

Additionally, the ADX2FD/B58 is a handheld wireless microphone transmitter compatible with Axient Digital Wireless Systems.

Please Note: When purchasing separate wireless components, please match their frequency bands to ensure proper system operation. This trasmitter is compatible with the C-Band models of the ADX5D, AD4Q and AD4D wireless receivers.

Features:
- Ability to transmit RF signal on two discrete carriers
- Optional 50mW High Power mode for driving increased power on a single frequency
- Durable, moisture-resistant, lightweight metal case in black finish
- Up to 6.5 hours of runtime with SB920A rechargeable battery when transmitting on two RF carriers (up to 9 hours battery life when transmitting on a single RF carrier)
- External contacts for docked charging with optional fully covered radome
- Diversity ShowLink enabled for remote transmitter control and automatic interference avoidance
- Two transmission modes: Standard for optimal coverage and new High Density for maximum system channel count and robust coverage
- Encryption-enabled, secure transmissio
Specifications:
- General
- Gain Offset Range: -12 to 21 dB (in 3 dB steps)
- Battery Type: SB920A Rechargeable Lithium-Ion
- Battery Run Time:
  Single-Carrier Mode: up to 9 hours
  Frequency Diversity: up to 6.5 hours
- Frequency Band: X55: 941-960 MHz
- Dimensions: (L x Dia) 10.0 x 2.0 in (254 x 51 mm)
- Weight: .74 lbs (338g)
- Housing: Cast Aluminum
- Audio Input
- Configuration: Unbalanced
- Maximum Input Level (1 kHz at 1% THD): 145 dB SPL, typical (SM58)

  RF Output
- Antenna Type: Integrated Dual-Band Helical
- Occupied Bandwidth: <200 kHz
- Channel-to-Channel Spacing:
  Standard Mode: 350 kHz
  High-Density Mode: 125 kHz
- Modulation Type: Shure Axient Digital Propietary
- Power:
  - Single Carrier Mode: 2 mW, 10 mW, 20 mW, 50 mW
  - Frequency Diversity Mode: 2 x 20 mW
- Specific Absorption Rate (SAR): <0.21 W/kg

  Showlink
- Network Type: IEEE 802.15.4
- Antenna Type: ZigBee Dual Conformal
- Frequency Range: 2.40 to 2.4835 GHz (24 Channels)
- RF Output Power (Varies By Region): 10 dBm (ERP)
Item Includes:
- 1x Shure ADX2FD/B58 Axient Digital Handheld Transmitter with BETA 58 Capsule
- 1x SB920A Shure Rechargeable Battery
- 1x Zipper Bag
- 1x Threaded Adapter
- 1x Swivel Adapter, Black
Warranty:
- 2 Year Limited Warranty
