StarTech USB3HDCAP USB 3.0 Video Capture Device - HDMI / DV

ITEM #: ST-USB3HDCAP MFG #: USB3HDCAP

Primary Image
  • Product Image Thumbnail 1 of 4
  • Product Image Thumbnail 2 of 4
  • Product Image Thumbnail 3 of 4
  • Product Image Thumbnail 4 of 4
Free Shipping with $49 Minimum Order

List Price:

$187.99

Our Price:

$187.49

Availability: Ships Factory Direct, Typically in 3-10 Business Days
iAvailability Description Popup


    USB3HDCAP - Overview

    This USB 3.0 external video capture device lets you record 1080p HD video and stereo audio to your computer system. With multiple video inputs including HDMI, DVI, VGA and component, the capture card can record original content from various sources such as computers, camcorders, security systems, POS terminals, and servers. With a framerate of 60 FPS (frames per second) and H.264 encoding, this is the perfect solution for capturing high-definition video for editing, compiling, and archiving.

    Seamless picture quality at 60 FPS
    Record lossless video at 60 FPS ensuring every frame of content is saved, unlike 30-frame-per-second capture devices that only catch half the action. 60 FPS exactly matches the output of most computer video cards, which is great for recording the output from your PC, server, or POS station when creating software training and tutorial videos.

    H.264 encoding for wide device compatibility
    The included software encodes in H.264, the most widely adopted video codec in the world, ensuring your video captures will be compatible with almost any device platform such as PC, Mac, iOS and AndroidT with no editing or converting required. H.264 is also widely supported by most software titles including Adobe Premiere and Windows Media Encoder. Plus, the software not only lets you capture and export videos, but it also lets you take screenshots, schedule recordings and instantly stream your video source over the Internet using online services such as Twitch or Justin.TV.

    This USB capture card is capable of capturing lossless raw video making it compatible with Microsoft DirectShow. With raw video capture you can record video using your preferred third party DirectShow software such as Open Broadcaster Software (OBS).

    Flexible Input Solutions for Convenient Compatibility
    With multiple A/V input options you can capture from a wide variety of sources including HDMI, DVI, VGA, and component. You can also use this capture card with A/V adapters to record other video sources such as SDI using our SDI to HDMI converter (SDI2HD). Support for a variety of A/V device is ideal for archiving analog video footage into a digital database.

    The device also includes easy-to-use software that's compatible with NTSC and PAL systems, making it a must for professional video archiving applications where source media can change from project to project.

    The USB3HDCAP is backed by a StarTech.com 2-year warranty and free lifetime technical support.

    Notes:Will not record digitally encrypted content. Not compatible with ASmedia, or Etron USB 3.0 host controllers. If your system has one of these non-supported controllers you can alternatively add a PCI-express USB 3.0 controller card such as the StarTech.com PEXUSB3S4V, PEXUSB3S400 or PEXUSB3S4.

    • Features:

      • Seamless picture quality with USB 3.0 bandwidth enabling you to capture 1080p video at 60fps
      • Record from virtually any device, with support for HDMI, DVI, VGA, and Component video input sources
      • Supports 2-channel stereo audio (HDMI / RCA)
      • NTSC and PAL systems supportedSupports 16:9 and 4:3 aspect ratio

    • Specifications:

      • Computer System Requirements:
      • Operating System: Microsoft Windows Vista / 7 / 8 / 8.1 (32/64-bit)
      • CPU: i3 Dual Core 2.8GHz or higher
      • Memory: 2 GB
      • USB 3.0 host controller (Confirmed support with: Intel, Renesas (NEC), VIA, AMD, Fresco FL1100)

        Hardware
      • Audio: Yes
      • Converter Type: Format Converter
      • Industry Standards: NTSC, PAL-M, PAL-60, PAL
      • Video Encoding: MPEG4/H.264 NTSC, PAL-M, PAL-60, PAL Video Encoding: MPEG4/H.264

        Performance
      • Audio Specifications: HDMI or Component RCA Stereo
      • General Specifications: This product is not compatible with Etron USB controllers, or ASMedia 1042 / 1042A USB controllers.
      • Maximum Analog Resolutions: 1920x1080 (1080p/30/50/60)
      • Maximum Digital Resolutions: Video input: 1920x1080 (1080p/30/50/60) / Video Output: 1920x1080 (1080p/60)
      • Supported Resolutions: 1080i/p, 720p, 576i/p, 480i/p
      • Wide Screen Supported: Yes

        Connector(s)
      • 1 - USB 3.0 B (9 pin; SuperSpeed)
      • 1 - HDMI (19 pin)
      • 1 - DVI-I (29 pin)
      • 1 - Stereo Audio (2 x RCA)
      • 1 - Component Video (3 x RCA)
      • 1 - Composite Video (1 x RCA)
      • 1 - VGA (15 pin; High Density D-Sub)
      • 1 - S-Video (4 pin; Mini-DIN)

        Environmental
      • Humidity: 20-80% RH Non-Condensing
      • Operating Temperature: 32°F to 95°F
      • Storage Temperature:23°F to 1604°F

        Physical Characteristics
      • Product Height: 1 in
      • Product Length: 4.5 in
      • Product Weight: 3.7 oz
      • Product Width: 3 in
      • Shipping Weight: 14.5 oz

    • Item Includes:

      • 1x - USB 3.0 HD Video Capture Device
      • 1x - A/V breakout cable
      • 1x - DVI to VGA adapter
      • 1x - USB 3.0 Cable
      • 1x - Instruction manual

    • GTIN:

      0065030855952
