FWN2.00BK 10FT - Overview

The FLEXO WRAP (FW) FWN2.00 is an exclusive product engineered and manufactured by Techflex. FW provides the perfect solution to a wide variety of unique application challenges. All grades of FW cut cleanly with a hot knife.

The color matched hook and loop closure provides for easy on and off installation, as well as instant and convenient access for harness break-outs and rework of any specific section along the entire length of the run. Combined with the expandable, open weave design, FW will conform to a wide variety of bundle diameters and will wrap around irregular shapes.

  • Specifications:

    • Physical
    • Monofilament Thickness (ASTM D-204): .010
    • Recommended Cutting: Hot Knife
    • Color: Black
    • Wall Thickness: .025
    • Tensile Strength - Yarn (ASTM D-2265) 7.5 lbs.
    • Abrasion Resistance: Medium
    • Specific Gravity: 1.38
    • Moisture Absorption % (ASTM D-570): .1 - .2
    • Nominal Size: 2"
    • Hook & Loop Width: 5/8"
    • Weight: 3.2 lbs

      Hard Vacuum Data (ASTM E-595 at 10-5 torr)
    • TML: .19
    • CVCM: .00
    • WVR: .16
    • Smoke D-Max (ASTM E-662): 56
    • Outgassing: Medium
    • Oxygen Index (ASTM D-2863): 21

      Operating Temperatures
    • Minimum Continuous: -94°F
    • Maximum Continuous (MIL-I-23053): 257°F
    • Melt (ASTM D-2117): 482°F

      Other Information
    • Halogen Free: Yes
    • RoHS: Yes
    • SVHC: None
    • UL/CSA: Yes
