Tokina Cinema TO-TC-16EXP-PP 1.6x EXPANDER PL to PL Mount

ITEM #: TO-TC-16EXP-PP MFG #: TO-TC-16EXP-PP

Primary Image
  • Product Image Thumbnail 1 of 2
  • Product Image Thumbnail 2 of 2

This item is no longer available.
Ask a Markertek Expert if you need assistance finding an appropriate substitute.

(800) 522-2025Email

Items similar to the TO-TC-16EXP-PP

TO-TC-16EXP-PP - Overview

Tokina created the 1.6x Expander so that cinematographers can use their favorite Super35 PL lenses on the latest full-frame 6K/8K cameras. The Expander increases the diameter of image circle by 1.6x on Super35 PL prime and zoom lenses. This allows for a greater variety of lens choices when filming with cameras like the RED Dragon that has a 46.31mm (8K) diagonal sensor.

Tokina engineers gave special attention to the 7-element optical design to ensure the integrity of the original lens’ performance and to keep light fall off to a manageable 1.36 stops. The all mechanical design is robust, durable, and lightweight.

The Tokina 1.6x Expander performs best when used with lenses that have a T2.0 or larger aperture and when the lens is stopped down to T2.8 or smaller.

  • Features:

    • Adapts PL Lens to PL-Mount Camera
    • Compatible with Super35 Format Lenses
    • Enlarges Image Circle by 1.6x
    • For 6-8K HD Sensors up to 1.85"
    • Seven Elements in Four Groups
    • Aperture Compensation of 1.36 T-Stops
    • Works Best with T2.0 or Larger Apertures

  • Specifications:

    • Focal Length Extension: 1.6x
    • Optical Structure: 4 Groups 7 Elements
    • Maximum Diameter: 83mm
    • Weight: Approx. 0.3kg
    • Max.Image Input: 29.3
    • Max.Sensor: 46.9
    • Max.Input T-Stop: 2
    • Lens Mount: PL
    • Camera Mount: PL

  • Warranty:

    • Limited 2-Year Warranty

  • GTIN:

    4968808220432
