Designed for board rooms, conference rooms and AV presentation!
The TOA AV-60S-AM is a single channel digital amplifier for speech and general announcement. This compact amplifier is equipped switching power supply circuit inside, Energy Star 3.0 certified and PLENUM rated (UL 2043 tested) for the installation into air handling space without external AC adaptor. The rated output power is 60W at 70V or 4Ω.
-
- Micro Class D amplifier for use in meeting/ board rooms & signage applications
- UL 2043-rated for plenum installation
- Energy Star® certified, now including Auto Power Down (APD) with user-selectable Standby and Non-Standby operation
- Standby Mode: Amplifier enters sleep after ~20 minutes of no signal and automatically wakes when audio returns
- Non-Standby Mode: Amplifier remains active at all times
- APD configuration accessible via tact-switch connection to Remote Volume Control port
- L/R Line inputs via: removable Transformer
- Balanced Terminal Block, ⅛" TRS mini-jack and RCA connections
- Bass & Treble Controls
- Remote Volume Control port for use with 10k Ohm
-
- Power Source: 100V - 240V AC, 50Hz/60Hz
- Rated Output: 60W @ 4Ω, 60W @ 70V, single output
- Power Consumption:
- Less than 85W @ 70V, Less than 110 W @ 4Ω
- Idle Less than 10W @ 70V, Less than 7W @ 4Ω - Frequency Response:
- 4Ω Mode: 20Hz - 20KHz ±3dB
- 70V Mode: 60Hz - 20KHz ±3dB (Line1 input with transformer: 100Hz - 20kHz) - Total Harmonic Distortion: Less than 0.15%
- Input:
- Line 1 -10/-20dB* (selectable), 10kΩ, transformer-balanced, removable terminal block
- Line 2 -10/-20dB* (selectable), 10kΩ, unbalanced, 3.5mm stereo jack
- Line 3 -10/-20dB* (selectable), 10kΩ, unbalanced, RCA jacks - Output: Speaker output, removable terminal block (2P)
- Tone Control:
- Bass: ±10dB at 100Hz
- Treble: ±10dB at 10kHz - Control:
- Master volume control
- Remote volume control
- Bass tone control
- Treble tone control
- 70V/4Ω switch
- Input sensitivity switches (Line1, Line 2, Line 3) - Indicator:
- Power LED
- Protection LED
- Signal LED
- Peak LED - Other Feature:
- Automatic level Control
- Thermal/Over-current protectionon
- Automatic power save function (EnergyStar rated) - Operating Temperature: 14°F - 104°F (-10°C - 40°C)
- Finish: Case: Black metal case
- Dimensions (WxHxD): 5.9" x 1.73" x 6.14" (150mm x 44mm x 156mm)
- Weight: 2.5lbs (1.12kg)
- Optional Accessories: WPB-20, MB-AV20RM, MT-S0301
-
- 2x Removable terminal plug (2P)
- 2x Removable terminal plug (3P)
- 1x AC power cord
- 4x Rubber feet
- 1x EMT adaptor plate
-
