Tripp Lite DWF2670X Fixed TV Wall Mount for 26 to 70 Inch Displays

ITEM #: TRL-DWF2670X MFG #: DWF2670X

Primary Image
  • Product Image Thumbnail 1 of 4
  • Product Image Thumbnail 2 of 4
  • Product Image Thumbnail 3 of 4
  • Product Image Thumbnail 4 of 4
Free Shipping with $49 Minimum Order

List Price:

$33.95

Our Price:

$32.00

Availability: Typically Ships in 3-10 Business Days
iAvailability Description Popup


    DWF2670X - Overview

    Mounts Your TV or Monitor on the Wall for a Perfect Viewing Angle
    Recommended for home theaters, classrooms, conference rooms, hotels, bars, restaurants or anywhere else you may want to show off a television or monitor, this Tripp Lite DWF2670X low-profile TV wall mount is hidden out of sight behind the display for a sleek, professional appearance. It fits most flat- and curved-panel displays from 26 to 70 inches and up to 165 pounds (75 kilograms).

    Durable All-Metal Construction Provides Convenient Cable Access
    The fixed TV wall mount is constructed from heavy-duty steel with a powder-coated black finish that resists scratches. Its open frame design with smooth edges enables easy access to cables. Horizontal mounting rails adjust to compensate for off-center wall studs. A built-in bubble level helps ensure your display is evenly mounted. Removing and replacing the display is fast and simple using the automatic spring locks with quick-release cords.

    VESA-Compliant Mounting Ensures Display Compatibility
    VESA (Video Electronics Standards Association) promotes uniformity in the video electronics industry by developing standards for TVs and monitors. For hassle-free display compatibility, this mount supports the following VESA mounting hole patterns: 50x50, 75x75, 100x100, 100x150, 100x200, 150x100, 150x150, 200x100, 200x200, 200x400, 300x200, 300x300, 350x350, 400x200, 400x300 and 400x400. Mounting hardware is included.

    • Features:

      • Accepts most popular flat- and curved-screen displays from 26 to 70 in. up to 165 lb.
      • Automatic spring locks with quick-release cords ensures quick and easy display removal
      • Adjustable horizontal mounting rails help compensate for off-center wall studs
      • Open architecture and built-in level enable easy cable access and accurate leveling
      • Conforms to current VESA standards to ensure compatibility with your display

    • Specifications:

      • Color: Black
      • Material of Construction: Steel
      • VESA Pattern (mm) : 50x50; 75x75; 100x100; 100x150; 100x200; 200x100; 200x200; 200x400; 300x200; 300x300; 350x350; 400x200; 400x300; 400x400
      • Motion: Fixed
      • Mounting Location: Wall
      • Degrees of Motion: Fixed
      • Distance from Wall (in.): 1.1
      • Minimum Screen Size (in.): 26
      • Maximum Screen Size (in.): 70
      • Maximum Weight Capacity (lbs.): 165
      • Number of Displays: 1
      • Unit Dimensions (hwd / in.): 16.500 x 17.240 x 1.100
      • Unit Weight (lbs.): 2.3
      • Assembly Required: Yes
      • Cord Management: No
      • Tools Necessary: Yes
      • Product Compliance: RoHS; RoHS3; REACH

    • Item Includes:

      • 1x DWF2670X Fixed TV Wall Mount
      • 1x Mounting hardware
      • 1x Owner's manual

    • Warranty:

      • 5-year limited

    • GTIN:

      0037332266095
