L6MAX - Overview

The Power of a Studio. The Freedom of a Compact Mixer.

Big Mixer Energy
The ZOOM LiveTrak L6max is packed with all the features you'd expect from a full-size mixer, plus a multi-track recorder. It's compact, battery powered, and ready to be the centerpiece of your live show, rehearsal or podcast.

Small Enough For A Duo, Big Enough For A Band
Whether you are a full-band, an acoustic duo or a solo performer, the L6max is ready. With 4 combo inputs (including 2 with Hi-Z) and 8 line inputs, its 12 channels offer the flexibility you need for any session.

Unlimited Overdubbing
You can mix and bounce tracks to the dedicated 'bounce track' freeing up additional channels to keep adding layers. If the bounce doesn't hit the mark, 'undo' it and try again. Even after a bounce Individual files are saved to the SD card for future mixing.

AI Noise Reduction
Turn on AI Noise Reduction and let the L6max intelligently remove hum, hiss, and background noise-while preserving every detail of your voice and instruments.

Let's Get Loud
For huge drums and loud guitar solos, the L6max records clip-free audio in 32-bit float. Channels 1-4 have dual-AD converters, keeping mic signals pristine across extreme dynamics.

3-Band EQ for Every Channel
Dial in the perfect tone with LOW, HIGH, and MID EQ on each channel.

Onboard Effects
Build the perfect mix with onboard effects including Reverb, Delay, and Echo. Use the TAP key to set delay times.

Advanced Compressor
The master track compressor adds punch and saturation to your mix. With 32-bit float the audio will never clip, even at high volumes.

**AA batteries sold separately

  • Features:

    • Custom Monitoring Options
    • High-Output Ready
    • OLED Display
    • Powerful Multi-Tracking
    • 14 Tracks of Recording
    • Unlimited Overdubbing
    • AI Noise Reduction
    • 3-Band EQ for Every Channel
    • Onboard Effects
    • Advanced Compressor
    • Easily Record with your Smartphone or Computer
    • Flexible Routing with AUX Sends
    • Scene Memory
    • Sound Pads with MIDI Sync
    • MIDI I/O and USB MIDI
    • Customize with the L6 Editor App


  • Specifications:

      Numbers of Input and Output Channels
    • Inputs:
      - Mic/Line (mono): 4
      - Line (stereo): 4
    • Outputs:
      - Aux Send (mono): 2
      - Master (stereo): 1
      - Monitor (stereo): 1
      - Sub-Out (stereo): 1

      Inputs
    • Mic/Line:
      - Connectors: 4 XLR/TRS combo jacks (XLR: 2 HOT, TRS: TIP HOT)
      - Input Gain: Adjustment unnecessary (dual A/D converter circuits used)
      - Input Impedance:
       • XLR: 3.8 kΩ or more
       • TRS: 18 kΩ or more (when Hi-Z off) / 1 MΩ or more (when Hi-Z on)
      - Maximum Input Level:
       • XLR: +4 dBu
       • TRS: +24 dBu
      - Phantom Power: +48 V Channel total 20 mA or less
    • Line:
      - Connectors: 8 TS phone jacks
      - Input Impedance: 30 kΩ or more
      - Maximum Input Level:
       • +4 dBu (when PAD is 0 dB)
       • +24 dBu (when PAD is -20 dB)

      Outputs
    • Connectors:
      - 2 TRS Phone Jacks (impedance balanced)
      - Maximum Output Level: +9.5 dBu
      - Output Impedance: 147 Ω
    • Master:
      - Connectors: 2 TRS phone jacks (balanced)
      - Maximum Output Level: +15 dBu
      - Output Impedance: 147 Ω
    • Monitor / Sub-Out:
      - Connector: TRS phone jack
      - Maximum Output Level: 50 mW + 50 mW (63 Ω load)
      - Output Impedance: 14.7 Ω
    • Buses:
      - Master: 1
      - Sub-Mix: 1
      - AUX Send: 2
      - Send EFX: 1
    • Level Meters: 6 segments
    • Send Effects: 6 types

      Recorder
    • Maximum Simultaneous Recording Tracks: 14
    • Maximum Simultaneous Playback Tracks: 14
    • Recording Formats: 48kHz, 32-bit float, mono/stereo WAV
    • Recording Media:
      - microSDHC memory cards (Class 10 or higher)
      - microSDXC memory cards (Class 10 orhigher)
    • Card Reader: Mass storage class USB 2.0 High Speed

      Audio Interface
    • Numbers of Inputs and Outputs:
      - Input: 14 channels
      - Output: 4 channels
    • Sampling Frequency: 48 kHz
    • Frequency Response: 20 Hz - 20 kHz, -1.0 dB / +0.5 dB
    • Equivalent Input Noise: -120 dBu or less (IHF-A) at 150Ω input
    • Bit Depth: 32-bit float / 24-bit
    • Interface: USB 2.0

      Physical
    • Display: 128x64 OLED
    • Power: 4 AA batteries (alkaline, lithium, or rechargeable NiMH)
    • AC adapter (ZOOM AD-17): DC 5V/1A. USB bus power is supported
    • Power Consumption: 5 W maximum
    • Dimensions: 11.18" x 4.49" x 1.83" (284mm x 114mm x 46.5mm)
    • Weight (main unit only): 1.5 lb (673 g)
    • Weight (including batteries): 1.70 lb (767 g)


  • Item Includes:

    • 1x ZOOM LiveTrak L6max 12-Channel 14-Track Digital Live Mixer and Recorder
      **AA batteries sold separately
