Adam Hall 874E02 ERGO Series 19-Inch 2RU Steel Rack Drawer with Snap-Lock Function - 22lb Capacity

ITEM #: ADH-AH-874E02 MFG #: 874E02

Primary Image
  • Product Image Thumbnail 1 of 5
  • Product Image Thumbnail 2 of 5
  • Product Image Thumbnail 3 of 5
  • Product Image Thumbnail 4 of 5
  • Product Image Thumbnail 5 of 5
Adam Hall North America, Inc.
Free Shipping with $49 Minimum Order

Our Price:

$79.98

Add to Wish ListLeasing Options
Availability: Usually Ships in 5-14 Days.
Please Email, Chat or Call (800) 522-2025 for Detailed Delivery Info
iAvailability Description Popup
Report Lower PriceLarge Quantity Quote

874E02 - Overview

The Adam Hall 874E02 2RU ERGO Series Rack Drawer is a very affordable rackmount drawer with heavy-duty 0.06" (1.5mm) steel construction and easy, ergonomic operation. It integrates a recessed pull handle that runs the width of the drawer and a convenient push-to-close, pull-to-open latching mechanism with 3.31lbs (1.5kg) pull force. This economy rack drawer has a black semi-gloss powder coating finish and 22.05lbs (10kg) load capacity.

It features smooth-running full extension ball bearing slides with front disconnect for easy drawer removal!

  • Features:

    • 19" ERGO SERIES rack drawer with a vertical height unit of 2RU, is made from powdercoated steel for maximum robustness
    • All ERGO products are made with a continuous grip. This guarantees an ergonomic handling of the drawer
    • It comes with a snap-lock function with 3.31lbs (1.5kg) tensile strength, and is detachable
    • The drawer has a full-extension runner and can be loaded up to 22lbs (10kg)
    • Rack drawers are designed & engineered by Adam Hall 19" Parts® crew in Germany


  • Specifications:

    • Product Type: 19" Rack Drawers
    • Material: Steel
    • Surface: Powder coated
    • Color: Black
    • Outside Height: 2RU
    • Outside Width: 19.08" (484.6mm)
    • Outside Depth: 15.27" (387.8mm)
    • Inside Height: 3.17" (80.6mm)
    • Inside Width: 15.99" (405.9mm)
    • Internal Depth: 14.11" (358.5mm)
    • Material Thickness: 0.06" (1.5mm)
    • Maximum Load: 22lbs (10kg)
    • Weight: 14.77lbs (6,7kg)


  • Item Includes:

    • 1x Adam Hall 874E02 ERGO 19-Inch 2RU Steel Rack Drawer with Snap-Lock Function


  • Warranty:

    • 2 Year Warranty
