    AS-4CR - Overview

    The Adder AS-4CR Secure Card Reader allows users to stay logged-in on a CAC designated network whilst seamlessly switching between other networks. In time-critical situations, the secure Card Reader allows simultaneous authentication with up to four isolated computers - without the need to re-authenticate at the point of switching.

    Note: The buttons on the smart card reader are used to associate your smart card with particular computers, not to change channels on a KVM switch.

    • Features:

      • No Switching Re-Authentication: When used with a KVM Switch, it removes the need to re-authenticate when the user switches channels.
      • Auto-Disassociation: Immediately disassociates from all coupled computers when the card is removed.
      • Secure: No card or user data is accessible to the Reader. No data can pass between connected computers.
      • Industry Recognized: NIAP Protection Profile 4.0 Compliant.
      • Transparent operation: Source PCs are unaware of their peers and work seamlessly with the smartcard.
      • Tamper Proof Design: Physical casing, anti-tamper sensors and holographic labels minimize the risk of unauthorized access.
      • ISO7816 compliant: May be used with compatible smartcards and authentication applications. Uses standard smartcard reader chips from Identive (formerly SCM) and USB CCID drivers.
    • Specifications:

      • Approvals / Compliance
      • ISO7816
      • CE, UL and cUL, Saftey BSEN60950 / EN60950

      • Windows OS, XP version and above, Linux and Mac operating systems.

      • Operating temperature: 32 to 104F
      • Storage temperature: -4F to 140F
      • Operating humidity: -20 to 80% non-condensing
      • Storage humidity: -10 to 90% non-condensing

      • Mechanical: Sealed plastic design
      • Dimensions: 7.0" (w) x 1.34" (h) x 2.5" (d)
      • Weight: 1.1lbs
      • Power: 100 - 240V AC, 47-63Hz, 12V DC 5W output from power supply unit
    • Item Includes:

      • 1x Adder AS-4CR Secure 4-port KVM Switch CAC Card Reader
