ADJ VIN004 Vintage X Scenic Lighting Fixture with 4x 60W Amber LEDS and 64x 3W RGB LEDs - IP20 Rated

ITEM #: AMDJ-VIN004 MFG #: VIN004

Primary Image
  • Product Image Thumbnail 1 of 4
  • Product Image Thumbnail 2 of 4
  • Product Image Thumbnail 3 of 4
  • Product Image Thumbnail 4 of 4
Free Shipping with $49 Minimum Order

List Price:

$1,279.95

Our Price:

$919.99

Availability: Ships Factory Direct, Typically in 3-10 Business Days
iAvailability Description Popup


VIN004 - Overview

The ADJ VIN004 Vintage X is a highly adaptable scenic lighting fixture that sparks creativity and captures attention with its dual-purpose design. Featuring four 60-watt foreground amber LEDs (2000K), it produces the warm glow of a retro blinder effect, while 64 vibrant 3-watt RGB LEDs deliver rich, dynamic color tones and stunning background effects. This combination allows for smooth dimming transitions and bold, captivating lighting displays in an intriguing octagon shaped fixture.

With its wide 150-degree field angle, the Vintage X is perfect for stage productions, live events, and theatrical applications. Additional features include advanced strobing effects, retro background lighting, and silent operation, while its flicker-free performance guarantees smooth visuals. The fixture also boasts a user-friendly OLED display and compatibility with DMX, RDM, Bluetooth, and Aria X2 wireless management system for over the air firmware/software updates for streamline control.

Designed for flexibility, the Vintage X supports multiple control modes, and a coffin locking system to interlock up to eight fixtures together, making it ideal for immersive lighting environments. Combining classic vintage aesthetics with cutting-edge technology, it offers both creative versatility and reliable performance for modern lighting designs.

  • Features:

    • 4 Foreground Amber LEDs
    • 64 Background RGB LEDs
    • All LED's are Individually Controllable via DMX
    • Built-In Foreground LED Programs
    • Built-In Background LED Programs
    • Variable White Color Temperature Control (2,700K ~ 10,000K) (RGB LEDs)
    • User Selectable LED Refresh Rates (900Hz ~ 25K)
    • 6 User Selectable Dim Modes
    • 4 User Selectable Dim Curves
    • Electronic Strobe (0.1Hz ~ 20Hz)
    • Electronic Dimming

  • Specifications:

      Optical
    • 4x 60W, 2000K, Amber Foreground LEDs
    • 64x 3W RGB Background LEDs
    • 50,000 Hour Average Life
    • Amber: 2000K (±50K)
    • RGB: 2,700K - 10,000K White Color Temperature Range
    • Output: 220 Lux, 7000 to 8000 Lumens
    • 140° Beam Angle
    • 150° Field Angle

      Physical
    • IP20, Metal Housing
    • Safety Eyelet
    • Digital Display
    • Coffin Lock System to Interlock up to 8 Vintage X units
    • Adjustable Hanging Bracket

      Control
    • DMX512
    • Aria X2 Wireless Management/DMX System
    • Bluetooth
    • RDM and RDM Net Compatible
    • 9x DMX Channel Modes (8, 13, 22, 39, 43, 196, 200, 208 & 211 Channel modes)
    • On-board Manual Control Mode
    • Primary/Secondary Mode

      Connections
    • 5-pin XLR DMX In/Out Sockets
    • IP65 Locking Power In & Thru Sockets

      Electrical
    • Input: AC 100V - 230V/50Hz-60Hz
    • Power Consumption: 780W @120V, 750W @ 230V
    • Power Link: 1 piece @120V or 2 pieces @ 230V

      Size/Weight
    • Dimensions (LxWxH): 15.7" x 15.7" x 7.6" (398mm x 398mm x 194mm)
    • Weight: 18lbs (8.2kg)

      Power
    • AC 100V - 240V/50Hz-60Hz Input
    • 200W Power Consumption
    • Link 2 pieces @120V AC or 4 pieces @ 230V AC

      Thermal
    • Ambient Operational Temperature: -4°F - 113°F (-20°C - 45°C)
    • Storage Temperature: -22°F - 113°F (-30°C - 45°C)

      Certifications & IP Rating
    • CE (Pending)
    • cETLus (Pending)
    • FCC (Pending)
    • IP20

  • Item Includes:

    • 1x VIN004 Vintage X Light Fixture
    • 1x Safety Cable
    • 1x Power Cable

  • Warranty:

    • 2 Year Warranty

  • GTIN:

    0810087374105
