Learn More About The Apantac DA-SDI-DE-AA-BL SDI De-embedder with 1 x 2 SDI Distribution Amplifier


Apantac DA-SDI-DE-AA-BL SDI De-embedder with 1 x 2 SDI Distribution Amplifier
  • Apantac DA-SDI-DE-AA-BL SDI De-embedder with 1 x 2 SDI Distribution Amplifier
  • Apantac DA-SDI-DE-AA-BL SDI De-embedder with 1 x 2 SDI Distribution Amplifier

Questions? Ask a Markertek Expert:
800-522-2025 Email

Apantac DA-SDI-DE-AA-BL SDI De-embedder with 1 x 2 SDI Distribution Amplifier

Manufacturer: Apantac

Item #: APA-DASDIDEAABL   •   MFG #: DA-SDI-DE-AA-BL



List Price:$1,100.00
Our Price:$949.99

free ship


Availability: Direct Ship From Manufacturer
i
Item ships directly from the manufacturer and is subject to manufacturer availability. We will contact you with expected availability. You can also email [email protected], chat or call customer service (800)-522-2025 for expedited delivery options.


  • Special Order Item: non-cancelable, non-returnable, non-refundable.


Share!





SDI De-embedder with 1 x 2 SDI Distribution Amplifier (with reclocking). Auto detects 3G SDI (1080p - SMPTE-425M Level A) HD SDI (720p, 1080i) or SD SDI (525, 625). Dsub 25 Output with 8 AES and 16 Analogue Audio signals (Unbalanced). Order breakout cables separately. One AES output (75 Ohms - BNC) and one Analogue Stereo Audio output (Jack 3.5 mm). One rotary switch allows selecting one of the 8 embedded AES pairs and send it to the AES and the Analogue Stereo Audio outputs. Bargraphs on top display the 16 embedded audio signals. 62x113x29 mm (WxDxH) - Magnetic base


  • Features

    • Input: Supports SDI up to 3G
    • Output: 16 channels of analog audio and 8 pairs of AES audio
    • 2 Looping Inputs
    • Any pair of audio can be selected for monitoring

  • Specifications

    • DESCRIPTION:SDI De-embedder. Supports up to 16 channels Analog audio and 8 pairs of AES
    • INPUTS: 1 x SDI Data rates: 125 Mbps to 2.97 Gbps
    • OUTPUTS: 2 SDI out
    • Up to 16 channels of analog audio and 8 pairs of AES audio
    • POWER: DC 5V, 1000 mA
    • WEIGHT: 1 lb (0.45 kg)
    • DIMENSIONS: 62 W x 113 D x 29 H (mm)
