ART MX225U 5 Zone Stereo Dual-Source Distribution Mixer

MX225U - Overview

Perfect for restaurants, conference rooms, houses of worship, and more!

• Features:

  • Left and right balanced Source 1 and 2 Inputs, accepts stereo or mono signal sources
  • Source 1 and 2 input channels are internally routed to all five Zone channels Five Zone channels each feature Source 1 and 2 level controls and left and right balanced output XLR connectors
  • Stereo/Mono selector on each zone sums left and right into Mono mode when engaged
  • Mono indicator LED on each zone channel indicates that mono has been selected
  • Five LED level metering (-25, -20, -15, -10, Clip) on each zone channel indicate signal activity for each zone.
  • Source 1 and 2 indicator LEDs show you when a signal is present in each source channel


• Specifications:

  • Inputs: 4x XLR
  • Outputs: 10x XLR
  • Input Impedance: 47kΩ
  • Output Impedance: 200Ω
  • Maximum Input Level: +20dBu
  • Maximum Output Level: +24dBu balanced
  • Maximum Gain: +6dB
  • Total Harmonic Distortion: 0.05% Typical
  • Signal to Noise Ratio: > 90dB typical
  • Power Requirements: 105V - 125VAC/50-60Hz, 15W typical
  • Dimensions (LxWxH): 7.25" x 19" x 1.75" (18.4cm x 48.3cm x 4.45cm)
  • Weight: 5.34lbs (2.42kg)


• Warranty:

  • 3 Year Limited Warranty
