ATEN US3344I 4x4 USB 3.1 Gen 1 Industrial Hub Switch - USB Type B - 4 USB Port(s)

ITEM #: ATEN-US3344I MFG #: US3344I

  • Product Image Thumbnail 1 of 3
  • Product Image Thumbnail 2 of 3
  • Product Image Thumbnail 3 of 3
free ship

List Price:

$231.00

Our Price:

$186.50

Availability: Extended Lead Time. Email, Chat or Call Us for more details.
iAvailability Description Popup


    US3344I - Overview

    The Aten US3344I is a 4-port USB3.1 Gen1 Industrial Switch that enables 4 computers to share and use USB3.1 Gen1 devices such as keyboard, mouse and other peripheral devices. The peripheral focus can be manually given to a particular computer by using pushbutton connected to the switch.

    It eliminates the cost to implement the complicated redundant systems and equipment for each computer. The US3344I chassis and rack mountable design is suitable for any industrial environment. For extra convenience, it features an external remote control port that can simplify cabling layout via traditional RS422 / RS-485 signals.

    The US3344I allows for a neat and tidy installation - The USB cables are bundled to save the extra cost of purchasing USB cables.

    • Features:

      • Enables four computers to share USB peripheral up to four devices
      • Supports USB 3.1 Gen1 specification, maximum data transfer rates up to 5Gbps
      • Multiplatform support - Windows, Mac and Linux
      • LED indicators display port focus
      • Metal mechanical chassis with wall mountable designs
      • Support aftermarket USB M2 screw locking cable
      • Support port selection via remote controller or RS-422/RS-485 link through 5-pin terminal block
      • Hot pluggable
      • Support DC 9-24V power input by terminal block
      • Support Battery Charging V1.2 and over current protection

    • Specifications:

      • Connectors
      • Computer Connections: 4
      • Computer: 4x USB Type B Female (Blue)
      • Device: 4x USB Type A Female (Blue)
      • Serial: 1x 5-pin Terminal Plug (Green)
      • Power: 1x 2-pin 9-24V Terminal Plug (Green)
      • Power (Optional): 1x 12V DC Jack Female (Black)
      • Port Selection: Remote port selector / Serial command
      • LEDs:
        Selected: 4 (Green)
        Serial: RS422 (Orange)
        RS485: (Green)

        Cable Length
      • USB Cable:
        2x USB 3.1 Gen 1 Type-B to Type-A Cables 1.2M
        2x USB 3.1 Gen 1 Type-B to Type-A Cables 1.8M
      • Remote Port Selector: 1.8 m

        Environmental
      • Humidity (RH): 0 to 80% (non-condensing)
      • Operating Temperature: 32° to 122°F (0° to 50°C)
      • Storage Temperature: -4° to 140°F (-20° to 60°C)

        Physical Properties
      • Housing: Metal
      • Weight: 1.12Lbs (0.51kg)
      • Dimensions (LxWxH): 7.87 x 3.15 x 0.98" (20 x 8 x 2.50cm)
      • Note: For some of rack mount products, please note that the standard physical dimensions of WxDxH are expressed using a LxWxH format.

    • Item Includes:

      • 1x 4x4 USB 3.1 Gen 1 Industrial Hub Switch
      • 2x USB 3.1 Gen 1 Type-B to Type-A Cable 1.2M
      • 2x USB 3.1 Gen 1 Type-B to Type-A Cable 1.8M
      • 1x Remote Port Selector
      • 1x Mounting Kit
      • 1x Terminal Block Adapter Set (an RS-422/RS-485 and a DC terminal block adapter)
      • 1x User Instructions

    • GTIN:

      0672792009549
