ATEN VP1920 9 x 2 4K Presentation Matrix Switch - TAA Compliant 4096 x 2160 - 2x HDMI Out - 1x Displayport In

ITEM #: ATEN-VP1920 MFG #: VP1920

Primary Image
  • Product Image Thumbnail 1 of 3
  • Product Image Thumbnail 2 of 3
  • Product Image Thumbnail 3 of 3
Free Shipping with $49 Minimum Order

List Price:

$721.40

Our Price:

$685.33

Availability: Typically Ships in 3-10 Business Days
iAvailability Description Popup


    VP1920 - Overview

    The ATEN VP1920 is a 3-in-1 presentation switch that integrates a video matrix switch, an audio processor, and analog-to-digital converter functions. With nine multi-format inputs to two HDMI 4K outputs, it is designed to boost the efficiency and impact of professional presentations.

    With streamlined control from front panel push-buttons, IR remote controller, OSD, and RS-232, the VP1920 reduces not only system device count, but also lower operation complexity. It is suitable for all small-to-medium sized corporate and education presentation environments, such as meeting rooms, classrooms, training rooms, or any other presentation setting, such as in exhibition centers or hotels.

    • Features:

      • Supports multi-format 9 Inputs and 2 HDMI outputs:
      • VGA port supports universal analog input formats (RGBHV/RGBs/YCbCr/YPbPr)
      • Embed/De-embed Audio-HDMI/DisplayPort audio signals can be extracted to digital/analog audio signals; stereo / composite/component audio can be embedded to digital audio signals
      • High-definition Video with Optimum Output
      • Superior video quality up to 4096 x 2160@60Hz (4:2:0) / 4096 x 2160@30Hz (4:4:4) (HDMI/DP)
      • EDID ExpertT - automatically selects the optimum EDID settings for smooth power-up, high-quality display, and the best video resolution across connected devices
      • HDMI (3D, Deep Color, 4K); HDCP 1.4 compliant
      • Versatile, Streamlined Operation
      • Multiple control methods via front-panel pushbuttons, RS-232, OSD, and IR remote
      • Source preview - quickly identifies and switches to the target content
      • Selectable display modes (Matrix, Mirror, or PiP) for different presentation demands
      • Auto switching - automatically detects and switches to a new source as soon as it is connected for time-saving and convenience
      • Supports stand-by mode for power saving and fast waking up
      • Extended Flexibility for USB Peripherals
      • USB ports enable keyboard/mouse or touch panel control over the connected computers
      • Control focus for keyboard/mouse and USB peripherals can be individually switched to a designated computer source

    • Specifications:

      • Video Input
      • Interfaces:
        - 6 x HDMI Type A female (Black)
        - 1 x DP Female (Black)
        - 1 x HDB-15 Female (Blue)
        - 1 x Component (3x RCA female, Blue/Green/Red)
        - 1 x Composite (1x RCA female, Yellow)

        Video Output
      • Interfaces: 2 x HDMI Type A female (Black)
      • Max. Distance: Up to 15m

        Video
      • Max. Resolution HDMI:
        - Up to 4096 x 2160 / 3840 x 2160 @ 60Hz (4:2:0); 4096 x 2160 / 3840 x 2160 @ 30Hz (4:4:4)
        - DP: Up to 4096 x 2160 / 3840 x 2160 @ 30Hz (4:4:4)
        - VGA/Analog: Up to 1920x1200@60Hz
      • Compliance:
        - HDMI (3D, Deep Color, 4K)
        - HDMI/DP: HDCP 1.4 Compatible; Consumer Electronics Control (CEC)

        Audio
      • Input:
        - Stereo Audio: 1 x mini stereo Jack female (Green)
        - Composite/Component Audio: 2 x RCA female (Red/White)
      • Output:
        - Optical Audio: 1 x Toslink (Black)
        - Coaxial Audio: 1 x RCA female (Orange)
        - Stereo Audio: 2 x RCA female (White / Red)

        Connectors
      • Computers: 2 x USB Type B Female (White)
      • Console Ports:
        - Keyboard/Mouse: 2 x USB Type A Female (White)
        - Device: 2 x USB Type A Female (White)
      • Power: 1 x 3-prong AC Socket

        Control
      • RS-232: 1 x DB 9 female (Black)
      • IR: 1 x Mini Stereo Jack Female (Black)

        Switches
      • Power:
        - 1 x Pushbutton
        - 1 x Rocker
      • Video Input Port Selection: 6 x Pushbutton
      • Video Output Port Selection: 2 x Pushbutton
      • Selection:
        - Mode: 1 x Pushbutton
        - Menu: 1 x Pushbutton
        - Up (Unlock): 1 x Pushbutton
        - Esc: 1 x Pushbutton
        - Audio: 1 x Pushbutton
        - Preview: 1 x Pushbutton
        - Down: 1 x Pushbutton
        - Enter: 1 x Pushbutton

        LEDs
      • Video:
        - Source 1: HDMI/VGA: 2(Green)
        - Source 2: HDMI/DP: 2(Green)
        - Source 3: HDMI/AV/YPbPr: 2(Green)
      • USB Link:
        - Keyboard/Mouse: 2 (Amber)
        - Device: 2 (Amber)
      • EDID Settings: EDID Mode: Default / Port 1 / Remix

        Power
      • Maximum Input Power Rating: 100-240 VAC; 50-60Hz; 1.0A
      • Power Consumption:
        - AC110V:7.3W:60BTU
        - AC220V:7.3W:60BTU

        Environmental
      • Operating Temperature: 0-40°C (32° F - 104° F)
      • Storage Temperature: -20 - 60°C (-4° F - 140° F)
      • Humidity: 0 - 80% RH, Non-Condensing

        Physical Properties
      • Housing: Metal
      • Weight: 2.36 kg ( 5.2 lb )
      • Dimensions: (L x W x H) 43.72 x 16.36 x 4.40 cm (17.21 x 6.44 x 1.73 in.)

    • Item Includes:

      • 1x VP1920 9 x 2 Presentation Matrix Switch
      • 1x Power Cord
      • 1x IR Receiver
      • 1x IR Remote Control
      • 1x User Instructions

    • Warranty:

      • 2 Year Warranty
