Atlas C12BT60 12 Inch 2-Way Dome Tweeter Style Coaxial Speaker with 60 Watt 70.7V/100V Transformer

ITEM #: ATL-C12BT60 MFG #: C12BT60

  • Product Image Thumbnail 1 of 2
  • Product Image Thumbnail 2 of 2
free ship

List Price:


Our Price:


Availability: Ships Factory Direct, Typically in 3-10 Business Days
iAvailability Description Popup

    C12BT60 - Overview

    AtlasIED Model C12BT60 is a professional quality coaxial speaker for use where full range music and voice reproduction are desired. Model C12BT60 combines a 12" diameter low frequency reproducer and a 1" diameter high frequency, post-mounted reproducer. The unit features a curvelinear, treated paper cone for lower harmonic distortion and a built-in crossover network for determining proper frequency selection between the two reproducers.

    The competitively priced unit assures smooth frequency response in a high power handling mode. For best results, enclosures with a volume of 2 cu. ft. or greater (including AtlasIED Models Q4412 or Q4612) are recommended. A factory installed 60 watt line transformer is included with the package, however, the transformer can be easily bypassed for 8 ohm applications.

    • Features:

      • Coaxial Loudspeaker with 12" Diameter Low Frequency and 1" Diameter High Frequency Reproducer
      • Includes Factory-Installed Line-Matching Transformer
      • Mounts a Wide Selection of Atlas Sound Q Series Enclosures and Standard Baffles
      • Professional Quality Sound Reproduction at a Competitive Price
    • Specifications:

      • Frequency response: 33Hz - 21kHz
      • Sensitivity: 95dB (at 1W/1m)
      • Power taps: 7.5, 15, 30, 60
      • Speaker type: Full Range Coaxial
      • Dispersion: 90°
      • Depth: 4 3/16" (10.63625 cm)
      • Shipping weight: 5.00 lbs (2.27 kgs)
    • GTIN:


    C12BT60 - Required Accessories

      C12BT60 - Recommended Accessories
