Belden 7936A DataTuff Category 5e Four Bonded-Pair 24AWG Bare Copper Cable - LSZH Jacket - Black - 1000 Foot

Name: Belden 7936A DataTuff Category 5e Four Bonded-Pair 24AWG Bare Copper Cable - LSZH Jacket - Black - 1000 Foot
Brand: Belden
SKU: BL-7936A-1000BK
Price: 2899.00 USD
Availability: PreSale

ITEM #: BL-7936A-1000BK MFG #: 7936A 0101000

Belden

List Price:

$3,501.20

Our Price:

$2,899.00

Add to Wish List Leasing Options

Availability: Usually Ships in 5-14 Days.
Please Email, Chat or Call (800) 522-2025 for Detailed Delivery Info

Notify when in stock

Report Lower Price Large Quantity Quote

Required Accessories

Recommended Accessories

7936A 0101000 - Overview

The Belden 7936A is an Industrial Ethernet Cat 5e cable with a 4 Bonded-Pair 24AWG (Solid) Bare Copper, PO Insulation, Overall Beldfoil Shield, LSZH Outer Jacket, CMG-ST1, NFPA 130.

Applications Include:
- Noisy environments
- Shipboard
- Transportation
- Harsh environment
- IIoT
- Factory or process automation
- IP cameras and devices
- Data communication

Specifications:
- Cable Type: Multi-Pair, Cat5e
- Number of Conductors: 8 (4 Pair Twisted)
- Wire Gauge: 24 AWG
- Conductor Strand: Solid
- Conductor Material: Copper, Bare
- Jacket (Insulation) Material: Low Smoke Zero Halogen (LSZH)
- Jacket (Insulation) Diameter: 0.265" (6.73mm)
- Shield Type: Foil
- Length: 1000.0' (304.8m)
- Jacket Color: Black
- Features: Drain Wire, UV Resistant
- Voltage: 300V
- Operating Temperature: 14°F - 167°F (-10°C - 75°C)
- Usage: Industrial, Network
- Conductor Insulation: Polyolefin (PO)
- Shield Material: Aluminum
- Shield Coverage: 100%

7936A 0101000 - Recommended Accessories

Belden RVUCOEW-B50 REVConnect Cable Core - 50 Pack
BL-RVUCOEW-B50
Our Price: $39.34
Belden RV6MJKUBKB24 REVConnect CAT6+ UTP Modular Jack - T568 A/B - Bulk 24 Pack - Black
BL-RV6MJKUBK-B24
Our Price: $231.00
Belden RVUTT01 REVConnect Universal Termination Tool for use with REVConnect Core RJ45 Connectors
BL-RVUTT01
Our Price: $133.76
Belden RVUDCBK-B24 Dust Caps for all REVConnct Jacks - Pack of 24 - Black
BL-RVUDCBK-B24
Our Price: $8.38
Belden RVAMJKUBK-B24 REVConnect 10GX T568 A/B UTP RJ45 Modular Jack Coupler - Black - 24-Pack
BL-RVAMJKUBK-B24
Our Price: $395.00
JackReel-3 High Capacity Low Cost Cable Reel
JACKREEL-3
Our Price: $59.95
Belden AX102263 KeyConnect Blank Module Insert - Black
BL-AX102263
Our Price: $0.48
Platinum Tools 21025C RJ45 Port Saver Cable
PLAT-21025
Our Price: $11.48
Triplett CTX200 PocketCAT RJ45 Ethernet - BNC COAX Network Cable Tester
BYB-CTX200
Our Price: $79.99

7936A 0101000 - Reviews

7936A 0101000 - Attachments

Belden 7936A Datasheet

Overview

7936A 0101000 - Overview

The Belden 7936A is an Industrial Ethernet Cat 5e cable with a 4 Bonded-Pair 24AWG (Solid) Bare Copper, PO Insulation, Overall Beldfoil Shield, LSZH Outer Jacket, CMG-ST1, NFPA 130.

Applications Include:
- Noisy environments
- Shipboard
- Transportation
- Harsh environment
- IIoT
- Factory or process automation
- IP cameras and devices
- Data communication

Specifications:
- Cable Type: Multi-Pair, Cat5e
- Number of Conductors: 8 (4 Pair Twisted)
- Wire Gauge: 24 AWG
- Conductor Strand: Solid
- Conductor Material: Copper, Bare
- Jacket (Insulation) Material: Low Smoke Zero Halogen (LSZH)
- Jacket (Insulation) Diameter: 0.265" (6.73mm)
- Shield Type: Foil
- Length: 1000.0' (304.8m)
- Jacket Color: Black
- Features: Drain Wire, UV Resistant
- Voltage: 300V
- Operating Temperature: 14°F - 167°F (-10°C - 75°C)
- Usage: Industrial, Network
- Conductor Insulation: Polyolefin (PO)
- Shield Material: Aluminum
- Shield Coverage: 100%
