Blustream UEX3C-KIT Bi-Directional USB-C / USB 3.2 5Gbps HDBaseT Extender Set over 328 Feet - USB-C Host to USB-C Device

UEX3C-KIT - Overview

Easy to use - plug and play!

• Features:

  • Supports USB 3.2 signal extension up to 328ft (100m)
  • Backwards compatible with USB 2.0 & 1.1 devices
  • USB3.2 Gen1 data transfer rate up to 5Gbps
  • 1x USB-C port on the receiver for connection to host device
  • 1x USB-C host charging port for connection of external power supply to power host device
  • 1x USB-A & 1x USB-C port on transmitter for connection to devices
  • Provides up to 2.5A combined power to USB devices (up to 1.7A per single USB port)
  • Configurable USB device power management via API commands
  • Bi-directional PoC (Power over Cable) to power extenders from either the host or device unit
  • PoC function can be enabled/disabled via dipswitch
  • Simple plug and play, no driver installation or setup required


• Specifications:

  • USB Hops: 2x USB hops / tiers for this extender kit
  • Box Dimensions (WxDxH): 8.6" x 6.5" x 2.5" (218mm x 165mm x 64mm)
  • Shipping Weight: 2.2lbs (1.0kg)
  • Operating Temperature: 32°F - 104°F (-5°C - 55°C)
  • Storage Temperature: -4°F - 140°F (-25°C - 70°C)


• Item Includes:

  • 1x UEX3C-H
  • 1x UEX3C-D
  • 2x Mounting kits
  • 1x 24V/1.5A power supply
  • 1x Quick Reference Guide


• Warranty:

  • 5 Year Limited Warranty
