    D2-220H/W - Overview

    Bolin was in a unique position to be among the very first to create Dante AV-H™ PTZ cameras. Dante AV-H™ is a software-based solution, it offers lower cost and network bandwidth requirements, with many of the core features of Dante AV™. These include compatibility with Dante Controller, up to eight channels of Dante audio, and Interoperability with AV-over-IP products from multiple vendors.

    Just like Bolin's Dante AV Ultra™ line of products, these cameras are designed to seamlessly integrate into an existing Dante audio ecosystem. The D2-220H/W PTZ camera is managed using Dante Controller Software, providing flexible, independent audio and Dante AV™ video routing across your network. Dante AV-H™ video can be sent to Dante Studio™ (Dante Video RX/TX and Viewer) for applications like live studio, video production, video conferencing, and educational cases.

    It is fully compatible with existing Dante systems.

    • Features:

      • High-Quality Imaging - Full HD: Bolin's Dante AV-H™ PTZ cameras are equipped with Sony sensor to provide brilliant, high-quality images in 1080p60 resolutions with 10x optical zoom.
      • Video Output: Deliver Dante AV-H™ version IP streaming video to the Dante network, and local HDMI video and USB streaming output to conventional workflows in FHD.
      • Multicast Mode: Point to Multipoint and Point-to-Point Distribution - supports both unicast and multicast video distribution.
      • Video Settings: Image parameter adjustments include exposure, focus, iris, shutter speed, white balance, gamma, wide dynamic range, image stabilizer, flip/mirror, and more with configurable video settings.
      • Audio: HDMI/SDI/USB embedded high-quality audio and Dante AV™ video streaming embedded audio with support for Mic-in and Line-in audio input. The audio that is input to the camera can be routed within a Dante audio over IP system.
      • PTZ Movement: Extremely quiet and smooth operation for Pan/Tilt movements combined with enhanced adaptive, variable, and super slow speed control provides accurate and effective operation experiences. Picture Profile Preset- Image parameter setting restore with presets and quick access operation.
      • Ease of Installation and Use: Simply connect one network cable from camera to any 1GB Ethernet network/POE device to access to existing Dante Audio-Over-IP system.
      • Always Up to Date: Firmware updates, upgrade via USB and IP interface to keep Dante AV-H camera features and performance up to date.
    • Specifications:

      • Image Sensor: Sony Progressive scan CMOS image sensor 1/2.8 type
      • Number of effective pixels: 1920X1080, 2.13 Megapixels
      • Zoom: Optical Zoom 20X, Digital Zoom 16X
      • Focal Length: f= 5.2 mm (Wide) to 104 mm (Tele)
      • Aperture: F1.6 (Wide) to F3.0 (Tele)
      • Horizontal Angle of View: 55.8° (W)~3.2° (T)
      • Vertical Angle of View: -
      • Min. object distance: 10mm (Wide)
      • Min. Illumination: 0.5lux(color),0.1lux(black)
      • Shutter Speed: 1/1 sec to 1/10000 sec (22 steps)
      • Focus: Auto, Manual, One Push
      • White Balance: Auto, Indoor, Outdoor,OPW,ATW, Manual
      • Exposure: Auto, Manual, Shutter /Iris /Brightness priority
      • Image Adjustment: Brightness, Color(Saturation), Contrast, Sharpness, HUE
      • Back Light Compensation: On/Off
      • E-Flip: On/Off
      • WDR: On/Off
      • Mirror: Horizontal
      • Day/Night: On/Off
      • Contrast: Yes
      • Color Gain: Yes
      • Color Hue: Yes
      • Color Matrix: Yes
      • Gamma: Yes, 0-4
      • High Sensitivity: Yes
      • Sence: Default, Clear, Bright, Soft
      • Focus Zone: Face Priority, All Area, Uper Area, Central Area, Lower Area
      • AI Face Detection Focus: Yes
      • AI Face Auto Exposure: Yes
      • Noise Reduction: 2D/3D, 1-255
      • S/N Ratio: ≥50db
      • OSD: Editable
    • Item Includes:

      • 1x Camera
      • 1x IR Remote Controller (2x AA batteries required)
      • 1x Camera Power Adapter
      • 3x Camera Power Cord (1x US, 1x EU, 1x UK)
      • 1x HDMI Cable Secure Mount
      • 1x Bag of Mounting Screws
      • 1x RJ45 to RS232 Extension Cable
      • 1x RJ45 to RS432 Extension Cable
      • 1x Welcome Card
    • Warranty:

      • 2 years
