Chauvet DJ GIGBAR3ILS GigBar 3 ILS 3-in-1 LED Lighting System

GIGBAR 3 ILS - Overview

Sends DMX or ILS signals wirelessly with built-in D-Fi transceiver

• Features:

  • 3-in-1 light that includes a pair of LED derbies, LED pars, and an LED strip, all mounted on one bar
  • Built-in LED strip adds pizazz and eye-candy effects to mobile entertainment setups
  • ILS compatibility for use in the ILS ecosystem
  • Built-in D-Fi transceiver communicates DMX or ILS signals wirelessly
  • Create the ultimate light show by mounting up to 4 additional fixtures to the top of the GigBar 3 ILS
  • Reversible tripod bracket allows for upside down mounting
  • Easy navigation and access all functions directly from the full-color LCD display
  • Get in and get out quickly with the included tripod, wireless footswitch, and FREE carry bags
  • Phenomenal, built-in, automated, and sound-activated programs that include all 3 effects to make one complete show
  • Easy control from the display, included RF Remote, wireless foot switch or DMX to take your gig to a higher level
  • Save time running cables and extension cords by power linking multiple units


• Specifications:

  • DMX Channels: 2, 21, or 132
  • DMX Connectors: 3-pin XLR
  • Strobe Rate: 0Hz - 20Hz
  • Operating Frequency: 2.412GHz - 2.484GHz
  • Power Linking: 11 units 120V; 18 units 230V
  • Input Voltage: 100V - 240VAC, 50/60Hz (auto-ranging)
  • Power and Current:
    - 47W, 0.7A 120V, 60Hz
    - 45W, 0.4A 230V, 50Hz
  • Light Source (pars): 6 LEDs (quad-color RGB + UV) 3.7W (1A), 50,000 hours life expectancy
  • Light Source (LED Strip): 74 LEDs (red, green, blue) 5W (0.03A), 50,000 hours life expectancy
  • Light Source (derby): 6 LEDs (2 red, 2 green, 2 blue) 3W (0.6A), 50,000 hours life expectancy
  • Stand Height: 4.8ft - 7.8ft (1.5m - 2.4m)
  • Tripod Leg Width: 3.9ft (1.2m)
  • Fits Tripod Size: 1.5" (37.4mm)
  • Beam Angle (pars): 13°
  • Field Angle (pars): 24°
  • Coverage Angle (Derby): 114°
  • Coverage Angle (LED Strip): 174°
  • Cable Length: 9ft (2.844m)
  • Foot Switch Operating Frequency: 433MHz
  • Foot Switch Max Unobstructed Distance: 100ft (30.5m)
  • Footswitch Battery: 9V 300mA
  • Optional Controllers: ILS Command, RF Remote
  • Weight: 13.2lbs (6kg)
  • Size: 41.2" x 3.7" x 10.7" (1047mm x 94.5mm x 272mm)
  • Approvals: CE, ROHS, FCC


• Item Includes:

  • 1x Gig Bar 3 ILS
  • 1x Power cord
  • 1x Stealth filter
  • 1x Wireless footswitch
  • 1x RF remote
  • 1x Tripod
  • 1x Carrying bag
  • 1x Tripod bag
  • 1x User Manual
