Creamsource K-CSV-24-ESS Vortex24 2x3 1950W Color LED Light Panel with Yoke - 2200K to 15000K Range

ITEM #: CRM-K-V-24-ESS MFG #: K-CSV-24-ESS

Primary Image
  • Product Image Thumbnail 1 of 5
  • Product Image Thumbnail 2 of 5
  • Product Image Thumbnail 3 of 5
  • Product Image Thumbnail 4 of 5
  • Product Image Thumbnail 5 of 5
Free Shipping with $49 Minimum Order

Our Price:

$16,499.00

Availability: Usually Ships in 5-14 Days.
Please Email, Chat or Call (800) 522-2025 for Detailed Delivery Info
iAvailability Description Popup
  • Shipped truck freight.


K-CSV-24-ESS - Overview

The Creamsource Vortex24 K-CSV-24-ESS is a high-powered lighting solution that delivers a whopping 1950W of illumination, three times the intensity of the Vortex8, making it ideal for projects that demand an extra level of brilliance. Despite its power, it retains the IP65 rating and the trusted build quality that Creamsource is renowned for, ensuring durability and reliability.

The Vortex24 LED Light is not just about raw power; it's also about precision and control. With 24 directional pixel zones, it allows for nuanced lighting effects and complex simulations such as fire and motion. Its smooth dimming feature ensures consistent brightness across all intensities, while the advanced color accuracy prevents color drift, ensuring your visuals are always true to life.

This LED light is powerfully efficient, drawing 1950W of power, making it suitable for standard circuits. It also includes a 'House Power' setting for 15A circuit operation. The compact design of the Vortex24 is complemented by its networking simplicity. Equipped with dual 1Gb Ethernet ports and a built-in Gigabit switch, it enables single-cable runs and daisy-chaining of units for efficient light array management. This feature simplifies control with protocols like sACN, making it an ideal choice for professional setups.

The Vortex24 also features a quick-adjustment front latch system, allowing for swift swaps of diffusers and accessories. It comes with a medium flat diffuser for immediate light softening, enhancing setup versatility without the need for additional purchases.

The Vortex24 is powered by Creamsource's new software architecture, which supports industry-standard features, protocols, and connectivity mediums. This makes the future evolution of CreamOS very exciting. The new feature set is wrapped into a new user interface, enhancing the user experience.

At the heart of the Vortex24 is the Creamsource Color Management System (CCMS). This advanced system unifies Vortex and Micro fixtures with a unique LED mix, meticulous factory calibration, and sophisticated software algorithms done in native CIE xy color space. It ensures consistent, high-quality light output across devices, maintains color accuracy at all dimming levels, and compensates for temperature changes.

The RRGBBW (red+deep red, green, blue+royal blue, white) LED configuration of the Vortex24 enriches red saturation, enhances warm whites, allows for deeper and brighter blues, and improves the quality of cool whites. This configuration outperforms traditional RGBW setups, making the Vortex24 2x3 1950W RRGBBW LED Light a superior choice for your lighting needs.

  • Features:

    • Offers 24 pixel zones for precise, dimmable lighting effects with consistent color accuracy and no drift
    • IP65 water resistant with a built-in power supply and all the advanced connectivity for professional use
    • Dual front-mount rails for easy modifier adjustments, allowing attachment and removal from the front, ideal for high setups or LNX rigs
    • Front latch system for quick diffuser and accessory changes; Includes medium flat diffuser
    • Dual etherCON ports with Gigabit switch for single-cable, daisy-chain setups

  • Specifications:

      Physical
    • Dimensions:
      - Fixture without Yoke: 38.2" x 27" x 10.2" (97cm x 68.6cm x 25.9cm)
      - Fixture with Yoke: 52.5" x 38.2" x 10.2" (133.3cm x 97cm x 25.9cm)
    • Weight:
      - Fixture without Yoke: 102.5lbs (46.5kg)
      - Fixture with Yoke: 117.9lbs (53.5kg)
    • Display: LCD
    • Environmental Resistance: Dust/Water-Resistant (IP65)
    • Operating Conditions: Up to 104°F (40°C)
    • Certifications: CE, CSA, ETL, FCC, RCM, UKCA
    • Materials: Aluminum, Polymer

      Power and I/O
    • Power Source: AC Power (Cable Included)
    • Inputs/Outputs:
      - 1x powerCON TRUE1 AC Power Input
      - 1x XLR 5-Pin DMX Input
      - 1x Unspecified Remote Input
      - 2x etherCON/RJ45 Network Input/Output
      - 1x USB-A Service Input/Output
    • Input Power: 110V - 240VAC, 50/60Hz at 17.7A
    • Included Adapter/Cable: 1x USA Type-A/B to powerCON TRUE1 Cable
    • Inline Switch: No
    • Power Consumption: 1950W

      Light Fixture
    • Item Type: 1x LED Light Panel
    • Included Filters: Diffusion
    • Color Temperature: 2200K - 15000K
    • Color Modes: RGB, Daylight, Tungsten
    • Dimming: 0% - 100% with High Resolution, Super-Smooth Low End Mode
    • Expected Lamp Life: 50,000 Hours
    • Beam Angle: 20°
    • Front Accessory Mount: Proprietary
    • Yoke Type: Manually-Operated Yoke
    • Fixture Mounting:
      - 1x 1⅛" Stud (Via Yoke Mount)
      - 8x ⅜"-16 Female Thread
      - Proprietary

      Photometrics
    • 20° at...
      - 8950 fc/96,350 Lux at 3.3ft (1m)(Unmodified)
      - 2560 fc/27,560 Lux at 9.8ft (3m)(Unmodified)
      - 1054 fc/11,350 Lux at 16.4ft (5m)(Unmodified)
      - 2502 fc/26,940 Lux at 3.3ft (1m)(with Filter)
      - 346 fc/3730 Lux at 9.8ft (3m)(with Filter)
      - 130 fc/1410 Lux at 16.4ft (5m)(with Filter)

  • Item Includes:

    • 1x Vortex24 2x3 1950W Color LED Light Panel
    • 1x Yoke
    • 1x Flat Diffuser
    • 1x Power Cable

  • Warranty:

    • 3 Year Limited Warranty

  • GTIN:

    0686696589670
