Draper 139109U Access E 16:9 Electric Projection Screen - 52-Inch x 92-Inch - Matt White

ITEM #: DR-139109U MFG #: 139109U

Primary Image
  • Product Image Thumbnail 1 of 5
  • Product Image Thumbnail 2 of 5
  • Product Image Thumbnail 3 of 5
  • Product Image Thumbnail 4 of 5
  • Product Image Thumbnail 5 of 5
Free Shipping with $49 Minimum Order

List Price:

$4,918.00

Our Price:

$4,299.00

Availability: In Stock - Ships Factory Direct, Typically in 6 Business Days.
Please Email, Chat or Call (800) 522-2025
iAvailability Description Popup
  • Shipment of this item is subject to a separate oversized-package carrier surcharge.
  • Shipped truck freight.


139109U - Overview

Plenum-rated housing easily installed in air-handling spaces!

The Draper 139109U is part of the Access E motorized projection screen series. This screen provides a ceiling-recessed solution that remains concealed when not in use for a clean architectural appearance. The free-hanging viewing surface maintains a flat appearance through the weight of the screen material and bottom dowel, making Access E an excellent choice for classrooms, boardrooms, training rooms, and other professional environments. A detachable bottom access panel simplifies service and maintenance, while quick-connect wiring allows the case to be installed during construction with the screen assembly added later. The plenum-rated housing is suitable for installation in air-handling spaces.

  • Features:

    • Maximum image width up to 16ft (4.88m), depending on viewing surface selection
    • Built-in controls may increase case length. Mounting brackets may add to overall case dimensions. See submittal documents for details.
    • Includes adjustable or removable hoisting brackets for easier installation
    • Black drop standard, depending on screen size. Extra drop available upon request and may increase case size.
    • Sliding brackets support mounting adjustments and accommodate different screen sizes
    • Detachable bottom access panel provides convenient service and maintenance access
    • Quick-connect wiring allows early case installation with the screen added later
    • Plenum rated for installation in air-handling spaces
    • Includes 110V 3-position wall switch. Quiet low-voltage motors and 220V options available.
    • Low-voltage controls, video interface options, and other control solutions can be integrated
    • White case standard

  • Specifications:

    • Surface Material: Matt White XT1000E
    • Image Format: HDTV 16:9
    • Image Area: 52" x 92"
    • Diagonal: 106"
    • Voltage: 110V
    • Motor Option: Low Voltage LVC-IV
    • Overall Size: 64" x 96"
    • Case Length: 109"
    • Case Dimensions (HxD): 7-3/8" x 8-1/16" (188mm x 205mm), including trim flange
