Hollyland MARS 400S PRO RX 400 Foot HDMI HD-SDI/3G-SDI Wireless Video Receiver

HL-MARS 400S PRO-RX - Overview

• Features:

  • Supports 1 Transmitter Connects With 2 Receivers
  • Supports Up To 2 Mobile Devices Monitoring While Only 1 Receiver Is Connected. Supports Up To 4 Mobile Devices Monitoring without Receiver connecting
  • OLED Display Screen
  • Channel Scan
  • Three Application Scene Modes
  • Battery Voltage Display
  • 400ft Transmission Range (LOS)
  • Lowest Latency is 0.1s
  • Both HDMI & SDI Connection Options
  • USB Firmware Upgradeÿ
  • Integrated Cold Shoe for Quick Installation
  • Supports DC Power,USB Type-C Power Supply and Battery Power Supply.


• Specifications:

  • Wireless
  • Wireless Range(with Transmitter): 400' / 121.92ÿm (Line-of-Sight)
  • Channel Bandwidth: 20 MHz
  • Frequency Range: 5 GHz
  • Latency: < 0.1 sec
  • RF Sensitivity: -80 dBm
  • Wi-Fi: Yes

    Interfaces
  • Receiver Antenna Ports: 2 x RP-SMA Male
  • Receiver Video Connectors: 1x BNC (3G-SDI) Output, 1x HDMI Output
  • Receiver Other I/O: 1x USB Type-C, 1x DC Input
  • Embedded Audio: SDI, HDMI

    Format Support
    SDI/BNC:
  • 1080p at 23.98, 24, 25, 29.97, 30, 50, 59.94, 60 fps
  • 1080i at 50, 59.94, 60 fps
  • 1080PsF at 23.98, 24, 25 fps
  • 720p at 50, 59.94, 60 fps
    HDMI:
  • 1080p at 23.98, 24, 25, 29.97, 30, 50, 59.94, 60 fps
  • 1080i at 50, 59.94, 60 fps
  • 720p at 50, 59.94, 60 fps
  • 576p at 50 fps
  • 480p at 60 fps

    Display
  • Receiver Panel Type: OLED

    Power
  • Receiver Battery Support: 1x Sony L-Series / NP-F Type
  • Receiver Power Connector: 1x Barrel (6 to 16V DC) Input
  • Receiver Power Consumption Device: (7 W)

    General
  • Receiver Mounting 1xÿ1/4"-20 Female, 1x Integrated Cold Shoe

    Materials Metal
  • Receiver Dimensions 4.33 x 2.83 x 1.34"
  • Receiver Weight 0.5lb


• Item Includes:

  • 1x Receiver
  • 3x Antennas
  • 1x Users Guide
  • 1x DC Adapter


• GTIN:

  0191460001482
