    A-DCFX9 - Overview

    IDX A-DCFX9 is a V-Mount adapter specifically designed for the Sony PXW-FX9. It converts the attached battery to the camera required 19.5V and supplies power via the DC input. By using it in combination with a small battery like the Imicro series, you can build a small and lightweight system that has a sense of unity with the camera. Also equipped with 2x D-Tap and an Alarm LED to alert battery level.

    • Features:

      • Converts attached V-Mount battery to 19.5V
      • 2x D-Tap output
      • Low level alarm LED
      • Fits 1x Sony BP-U30/35 battery
      • Capable of hot-swapping (BP-U battery must also be installed)

    • Specifications:

      • Battery Run Time (h:mm):Imicro-98: 3:00, Imicro-150: 4:15
      • Compatibility: Sony PXW-FX9
      • Output Connectors: (1) DC Plug, (2) D-Tap
      • DC Plug: Output rating: 19.5V (40W max), Outer diameter: 6.5mm, Inner diameter: 4.3mm, Pin diameter: 1.4mm, L-shaped type
      • D-Tap: Battery through voltage, 80W max
      • Alarm LED: Lights red when the battery level is 13.4V~11.5V
      • Ambient Temperature: Discharge: -20C~40C (10C~40C recommended)
      • Dimensions: 2.6(W) x 4.0(H) x 3.31(D) inches
      • Weight: 0.88 lbs approx.

    • Item Includes:

      • 1x IDX A-DCFX9 V-Mount Adapter for Sony PXW-FX9
