Libec ALX S12 Slider / ALX S12 Case

ITEM #: LIB-ALXS12 MFG #: ALX S12

Primary Image
  • Product Image Thumbnail 1 of 5
  • Product Image Thumbnail 2 of 5
  • Product Image Thumbnail 3 of 5
  • Product Image Thumbnail 4 of 5
  • Product Image Thumbnail 5 of 5
Free Shipping with $49 Minimum Order

List Price:

$607.00

Our Price:

$489.00

Availability: Ships Factory Direct, Typically in 3-10 Business Days
iAvailability Description Popup
  • Special Order Item: non-cancelable, non-returnable, non-refundable.


ALX S12 - Overview

The Libec ALX S12 is the perfect slider shooting with a smooth and delicate controllability. ALX S12 allows you to slide your camera on 2x 75mm or flat base tripods or on a tabletop. The sliding range is 43.5" and payload is 15kg / 33 lb. when used on a tabletop. This is achieved by the eight high-performance ball bearings applied with a special grease, which are installed in the slider platform. The ball bearings are positioned efficiently on the rail top and at an angle on both sides, hugging the rail to prevent wobbling during operation. The spring-equipped friction knob enables precise weight adjustment for a smooth sliding movement. The friction knob allows you to adjust sliding tension, and a brake knob sets the sliding rail in one place. Using the supplied hexagon wrench, pushing force of the ball bearing against the rail can be easily adjusted.

A dual base tripod mount adapter, featuring a 75mm ball base design with a flat bottom, allows direct compatibility with the ALX T tripod as well as other flat base tripods. A bubble level conveniently sticks out on the side for easy leveling. 1/4"-20 and 3/8"-16 threads are available on the top ends for attaching articulating arms with lights and other gear, and along the bottom for mounting the slider on two tripods. Rosette adapters are available on both sides for attaching rosette accessories. If you'll be using the slider on the ground or tabletop, you'll be able to adjust the height of the feet on either side if necessary. The feet simply screw in or out to be adjusted, and are tightened in position by knobs above them. Slider has collapsible tabletop legs for easy setup and storage.

All components are modular allowing users to have multi style configurations for any shooting environment, thanks to its detachable design. The rail can be easily detached and replaced with slider rails ALX SR4 or ALX SR8 by simply removing the leg lock knobs. The ALX SP slider platform has a 3/8"-16 threaded mounting stud, which directly supports the flat bottom of the dual base ALX H head. Adding an extra ALX H Head allows users to pan, tilt, and slide along the rail. In addition, a double platform configuration can also be achieved by having the following: 1x ALX S12, 1x ALXSP, 2x ALX H, 2x ALX T. Moreover, by using two platforms, a still image and a motion picture can be captured at the same time. Includes Padded Carrying Case with shoulder strap, tripod mount adapter and bowl clamp for flat base / 75mm ball diameter tripods, and a maintenance kit for longevity.

  • Features:

    • 43.5” slide range with a 15kg / 33lb Payload when used on a tabletop
    • 8 high-performance ball-bearings on the top and sides to allow for smooth, wobble-free motion
    • Tension / Friction knob, Brake knob, and bubble level
    • Equipped friction knob enables precise weight adjustments for a smooth sliding movement
    • Dual base tripod mount adapter and bowl clamp for flat base / 75mm ball diameter tripods
    • Components are modular and can be used with slider rails ALX SR4, ALX SR8
    • Slider rail can be easily detached and replaced by using the leg lock knob
    • Collapsible tabletop legs for easy setup and storage.
    • Height adjustable feet
    • Includes Padded Carrying Case with fixing handle and maintenance kit

  • Specifications:

    • Sliding Range 43.5" (1108mm)
    • Payload 33 lb. (15 kg)
    • Mount Types 3/8"-16 threaded head mounting stud
    • 3/8"-16 thread on bottom of tripod dual base adapter
    • 1/4"-20 and 3/8"-16 accessory mount threads
    • 1/4"-20 and 3/8"-16 threads along the bottom for mounting two tripods
    • Rosette adapters on the sides
    • Material Slider: Aluminum alloy and engineering plastic; Carry Case: Nylon
    • Tripod dual base adapter 75mm ball base/flat base (3/8"-16 thread on bottom)
    • Length 47" (1200mm)
    • Weight 5.5 lb. (2.5 kg)
    • Package Weight 12.0 lb.

  • Item Includes:

    • Slider with ALX SP Slider Platform with Friction knob, Brake knob, and bubble level
    • Dual Base Tripod Mount Adapter
    • Tripod Mount Fixing Handle
    • Collapsible / removable tabletop legs
    • Padded Carry Case for Slider
    • Maintenance kit
    • 3-Year Limited Warranty

  • GTIN:

    4986397411628
