Lake People F311 D F-SERIES 1RU 2-Channel Ultra-low-noise Microphone Preamp

F311 D - Overview

The F-SERIES from Lake People - high-level audio products with outstanding features!

• Features:

  • Electronically balanced inputs and outputs via XLR
  • Switchable lo-cut, 12 dB/oct. with 70 Hz corner frequency
  • 7-level display, -36 ... 0 dBr, internally calibratable
  • Precise step switches for adjusting the gain
  • Phantom power 48 volts switchable for 2 channels each
  • 5 Hz - 150 kHz @ - 3dB
  • 0 ... +66 dB switchable in 12 steps of 6 dB
  • Noise -129 dB at 60 dB gain
  • Unbalanced outputs via RCA


• Specifications:

  • Dimensions: 483 x 44 x 166 mm (BxHxT)
  • Output Impedance: < 30 Ohm
  • Input Impedance: 5 kOhm
  • Additional Features: Lo-Cut, 48V phantom power, phase reversal, 4-level meter
  • Housing: 19" / 1RU
  • Max. Output Level: > +25 dBu
  • Max. Input Level: > +21 dBu
  • Mic Gain: 0 - +66 dB
  • Noise: -129 dB (@ 60 dB gain)
  • Power Supply: Internal 230 V / 115 V AC
  • THD+N (@ -1 dBFs): < 0.001 %
  • Frequency Range: 5 Hz - 70 kHz (-3 dB)
  • Amplifier Channels: 2


• Item Includes:

  • 1x MIC AMP F311-D
  • 1x user manual
  • 1x power cord


• GTIN:

  7426923821875
