Mackie SRM150 5.25in Compact Powered PA System

ITEM #: MCK-SRM150 MFG #: SRM150

Primary Image
  • Product Image Thumbnail 1 of 3
  • Product Image Thumbnail 2 of 3
  • Product Image Thumbnail 3 of 3
Free Shipping with $49 Minimum Order

Our Price:

$299.99

Availability: In Stock
iAvailability Description Popup


    SRM150 - Overview

    The Mackie SRM150 Compact Active PA combines their proven mixer and SRM active loudspeaker technologies to create a powerful, great-sounding 3-channel PA system that is ultra-compact, versatile and expandable. The SRM150 is ideal for a wide variety of applications ranging from boardroom A/V to live musical performance in coffee houses, piano bars, or rehearsals, just to name a few.

    Don't be fooled by the small size. The SRM150 is big on features and sound quality. The built-in three-channel mixer features two combo XLR/line inputs (with true 48V phantom power), a stereo channel for CD/MP3 players, and Mackie's powerful 3-band Active EQ. The SRM150 can even be mounted on a mic stand, making it the ideal personal monitor. Put simply, with its tremendous feature set and 150-watts of world-class sound, the Mackie SRM150 is the perfect solution for any application requiring superior sound quality.

    • Features:

      • Extremely portable active loudspeaker system
      • Built-in Mackie mixer for superior sound quality with:
      • 3-channel mixer with 3-band active EQ
      • Two high-headroom Mackie Mic/line preamps with 48V phantom power
      • Instrument-ready input (no DI required)
      • Dedicated stereo channel for keyboards, CD, MP3, iPods, etc.
      • Neutrik Combo "line in" for linking or adding inputs
      • XLR "thru" with mic/line switch for linking more SRM150s or direct send to main PA
      • 150-watts of high output, Class-D power
      • 5.25" premium-quality, full-range neodymium driver
      • Frequency Response: 100Hz to 17.5kHz
      • Complete system protection with built-in limiter
      • 120 dB Maximum SPL@1meter
      • Built-in top carry handle
      • Integral aluminum heat sink
      • Mic stand integration system for use with stand and boom
      • Tough, impact-resistant, polypropylene enclosure

        **NOTE** Mic stand mountable with the supplied adapter via the built-in socket on the bottom of the cabinet

    • Specifications:

      • Acoustic Performance
      • Frequency Response (-3dB): 100Hz - 17.5kHz
      • Frequency Range: (-10dB): 60Hz - 22kHz
      • Max SPL Long-Term: 110dB @ 1m
      • Max SPL Peak: 120dB @ 1m

        Mixer Section
      • Frequency Response (-3dB): 5Hz - 40kHz (+0, -1dB)
      • Mic Input Impedance: 3kΩ balanced
      • HI-Z Input Impedance: 20kΩ balanced
      • Instrument Input Impedance: 1MΩ
      • Line/Stereo Input Impedance: 10kΩ balanced
      • Mic Input 1/2 Max Voltage Gain: 51dB
      • Stereo Input Max Voltage Gain: 9dB
      • Mic Max Input Level: -28dBu, gain @ +50dB; +15dBu, gain @ +6dB
      • Line Max Input Level: -8dBu, gain @ +30dB; +35dBu, gain @ -15dB
      • Stereo Max Input Level: +20dBu, gain @ 0dB
      • 3-Band EQ: ±15dB @ 12kHz (HI), 2.5kHz (MID), 100Hz (LO)
      • Thru Out Mic Level Pad: -30dB
      • Common Mode Rejection Ratio (CMRR): 55dB
      • Equivalent Input Noise (EIN): -129dBu
      • Residual Output Noise: -85dBu

        Power Amplifier
      • Rated Power: 100W
      • Max Power: 150W peak
      • Rated THD: <0.05%
      • Cooling: Convection Extrusion
      • Design: Class D

        Transducer
      • Diameter: 5.25"
      • Voice Coil Diameter: 1"
      • Magnet Material: Neodymium

        Power
      • Universal Power Supply: 100 - 240V AC, 50 - 60Hz, 35V AC
      • AC Connector: 3-pin IEC 250V AC
      • Operating Temperature: 32°F - 104°F

        Safety Features
      • Overload Protection: Limiter
      • Thermal Protection: Amplifier shutdown, auto-reset

        Construction Features
      • Material: Polyplopylene
      • Finish: Grey, textured finish
      • Handles: One on top
      • Grille: Perforated metal with weather-resistant coating
      • Display LEDs: Power ON, Phantom Power ON

        Physical
      • Dimensions (HxWxD): 8" x 11.2" x 6.8"
      • Weight: 7.6lbs

    • Warranty:

      • 3-year inclusive of electronics, 2-year drivers (where applicable), nontransferable

    • GTIN:

      0663961028379
