REAN NYS352G RCA Plug with Nickel Plated Shell and Gold Contacts

ITEM #: NYS352G MFG #: NYS352G

Primary Image
Rean
Free Shipping with $49 Minimum Order

Item unavailable. Please select another option.

Ask a Markertek Expert if you need assistance finding an appropriate substitute.

List Price:

$2.20

Our Price:

$1.32

Quantity Pricing

Add to Wish ListLeasing Options
Availability: In Stock
iAvailability Description Popup
Report Lower PriceLarge Quantity Quote

NYS352G - Overview

The Rean NYS352 is Heavy Duty Phono Plug with a nickel plated shell and gold contacts for cable with an O.D. of 7.2 mm.

  • Features:

    • Heavy duty phono plug
    • All metal
    • Cable O.D. up to 7.2 mm
    • Cable clamp strain relief


  • Specifications:

    • Electrical
    • Contact Resistance: ≤10mΩ
    • Insulation Resistance: ≥2,000MΩ
    • Dielectric strength 50Hz 0.5KVdc

      Mechanical
    • Insertion and Withdrawal Force: 5-20N
    • Lifetime: >5,000 mating cycles

      Material
    • Pin: Brass
    • Housing: Brass
    • Housing: Zinc
    • Insulation: PP
    • Cable Clamp: Steel
    • Pin: Tin and Cer
    • Cable Clamp: Tin and Cer
    • Housing: Nickel Plating
    • Housing: Nickel Plating
