P2P 12-Fiber LC/UPC Multimode OM3 50/125um Breakout Fanout Patch Cable - Aqua Jacket - 3.28 Foot - 12-Pack

ITEM #: P2P-PT12LCUOM-1M MFG #: P2P-PT12-LCU-OM3-1M

Primary Image
Point 2 Point Communications
Free Shipping with $49 Minimum Order

List Price:

$34.99

Our Price:

$29.99

Add to Wish ListLeasing Options
Availability: Usually Ships in 5-14 Days.
Please Email, Chat or Call (800) 522-2025 for Detailed Delivery Info
iAvailability Description Popup
Report Lower PriceLarge Quantity Quote

P2P-PT12-LCU-OM3-1M - Overview

The P2P PT12-LCU-OM3 is a premium-quality 3.28 foot (1 meter) 12-fiber breakout patch cable designed for high-speed multimode networking in data centers, enterprise backbones, and telecom rooms.

Featuring LC/UPC connectors and constructed with OM3 50/125µm multimode fiber, this aqua-jacketed fanout assembly enables low-loss, parallel connections for 40G/100G transceivers or MTP/MPO cassettes.

Each fiber branch is individually jacketed for protection, flexibility, and easy routing in dense rack environments.

The factory-tested connectors ensure low insertion loss and high return loss, while the tight-buffered, riser-rated design makes it ideal for both horizontal and vertical cabling.

Built to exceed industry standards, this cable is perfect for applications requiring space-efficient fiber distribution with high bandwidth performance.

Compatible with P2P CAMOSPLICE-432 fusion splicer

  • Features:

    • 12-Fiber LC/UPC Fanout Assembly: Enables high-density connections for parallel optics and breakout panels
    • OM3 50/125µm Multimode Fiber; Optimized for 10G/40G/100G data transmission with low attenuation
    • Individually Jacketed Fibers; Simplifies cable management and reduces risk of damage during handling
    • Aqua Outer Jacket; Color-coded for OM3 compliance and quick identification
    • Low Insertion & High Return Loss; Ensures reliable signal integrity and minimal loss in critical applications
    • 3.28 foot (1 meter) Length; Ideal for rack-to-rack patching in compact data center configurations


  • Specifications:

    • Fiber Type: OM3 50/125µm Multimode
    • Connector Type: LC/UPC to LC/UPC (12 fibers)
    • Length: 3.28 foot (1 meter)
    • Fiber Count: 12 (Fanout Configuration)
    • Cable Construction: Tight-buffered, breakout fanout
    • Jacket Color: Aqua (OM3 standard)
    • Jacket Type: Riser-rated (OFNR) or LSZH (optional)
    • Insertion Loss: ≤ 0.3 dB (Typical)
    • Return Loss: ≥ 35 dB (LC/UPC)
    • Standards Compliance: TIA/EIA-568, RoHS, ISO/IEC 11801, IEC-61754
    • Operating Temperature: -4°F to 158°F (-20°C to +70°C)


  • Item Includes:

    • 1x P2P 12-Fiber LC/UPC Multimode OM3 50/125um Breakout Fanout Patch Cable - Aqua Jacket - 3.28 Foot


  • Warranty:

    • 1 Year


  • GTIN:

    0743634044407
