    AW-UR100 - Overview

    Now You Can Remotely Capture Images in All Kinds of Outdoor Environments. Outdoor-ready Integrated 4K PTZ Camera That Captures Crucial Moments!

    Watching live broadcasts of outdoor sports and live performances through streamed video has become a popular form of entertainment. As the use of video for a variety of different business activities and daily life has become common, the capability to produce and utilize video with limited resources is becoming more important.

    The Panasonic AW-UR100 is a 4K PTZ camera that captures high-precision images in 4K/60p supported by D.I.S.S (Dynamic Image Stabilizing System). It is durable enough to withstand harsh outdoor environments for on-site management such as airports and warehouses in coastal regions, on ships, as well as for live broadcasts during heavy snowstorms or typhoons. A wide range of protocols and I/Fs enable flexible and efficient system construction and reduce the risk of missing shots and mistakes, providing peace of mind for video producers.

    High-precision video recording that does not miss any key scenes, even in large venues
    Thanks to a significant update from the AW-HR140, the wide-angle lens 4K/60p support, 24x optical zoom, and 10x digital zoom. The camera supports 4K/60p, 24x optical zoom, and 10x digital zoom. Three types of image stabilization, OIS, EIS, and D.I.S.S. (Dynamic Image Stabilizing System), suppress even low-frequency large-amplitude shaking.

    High-precision video recording is possible regardless of the installation environment, allowing the camera to capture a bird's-eye view of large stadiums and other venues while firmly targeting highlight scenes.

    Applications
    Broadcasting and distribution of sporting events, horse races, etc.
    Image capture at facilities and on large vessels in coastal areas
    Image capture for sports coaching
    Image capture and distribution as a weather camera or information camera

    • Features:

      • High-precision Image Capture That Never Misses Those Crucial Moments
      • Industry's first IP65-compliant, outdoor-ready integrated remote camera for 4K60p shooting
      • 24x optical zoom / 74.1° horizontal wide-angle images
      • Equipped with three types of image stabilizing systems: O.I.S, E.I.S, and D.I.S.S (Dynamic Image Stabilizing System)
      • Cropping (+ Zoom) Function

        Durability for Continuous Shooting Even in Harsh Environments
      • Passing Six Rigorous Durability Tests
      • Equipped with a Defroster (-15°C)
      • Equipped with a Wiper on the Lens

        Flexibility in System Construction
      • Various I/F and Supported Protocols
      • Compatible with FreeD, enabling construction of AR/VR systems

    • Specifications:

      • General
      • Power Requirements: DC 12 V to 21.8 V ±10 % (10.8 to 24.0 V)
      • PoE++: IEEE802.3bt compliant: DC42-57V (camera end)
      • (Compatible with software authentication (LLDP communication))
      • Ambient Operating Temperature: 5 °F to 113 °F
      • Allowable Humidity Ranges: 10% to 100%
      • Finish: Silver, salt damegement resistance treatment
      • Waterproof and Dust Proof: JIS C0920 protection class IP65 compliant
      • Maximum Permissible Wind Speed: 15 m/sec: Normal operation, 50 m/sec: Operable, 60 m/sec: Non-destructive
      • Wiper: Installed as standard
      • Heater: Installed as standard
      • Defroster: Installed as standard

        Camera Unit
      • Imaging Sensors: 1/2.5-inch 4K MOS x1, Total number of pixels: 3,864 x 2,218 = Approx. 8.57 megapixels, Actual pixels: 3,864 x 2,196 = Approx. 8.49 megapixels, Effective pixels: 8.29 megapixels
      • Lens: Motorized 24x optical zoom F1.8~F4.0, (f=4.12mm - 98.9mm, 35mm equivalent: 25.0mm - 600.0mm), i.Zoom (UHD: 28x, FHD: 36x) (*Switching between 24x optical -> iZoom -> Digital Zoom), D.Extender (1.4x, 2x), 10x digital zoom
      • Angle of view range: Horizontal: 74.1°(wide) - 3.3°(tele), Vertical: 46.0°(wide) - 1.9°(tele), Diagonal: 81.8°(wide) - 3.8°(tele)
      • Output format: (UHD/FHD SDI): 4K: 2160/59.94p, 2160/50p, 2160/29.97p (Native), 2160/25p (Native), 2160/24p (Native), 2160/23.98p (Native), HD: 1080/59.94p, 1080/50p, 1080/29.97p (Native), 1080/29.97PsF, 1080/25p (Native), 1080/25PsF, 1080/23.98p over 59.94i, 1080/24p (Native), 1080/23.98p (Native), 1080/23.98PsF, 1080/59.94i, 1080/50i, 720/59.94p, 720/50p

        Input
      • Input Connector: DC IN: DC 12 V IN
      • G/L IN: BBS (Black Burst Sync), tri-level sync supported

        Output
      • Video Output: SFP+: SFP+ compliant (Single Fiber)
      • 12G SDI OUT: SMPTE2082-1, SMPTE292 compliant/75 (BNC x1)
      • 3G SDI OUT: SMPTE424M / 75 (BNC x1)

        Input/Output
      • Input/Output Connector: LAN: LAN terminal for IP control (RJ-45)
      • RS-422: CONTROL IN RS422A (RJ-45)
      • D-sub 9 pin: External washer control terminals (#1: Washer_HOT, #6: Washer_COLD)

        Rotating Platform
      • Anti-vibration correction: D.I.S.S.(Dynamic Image Stabilizing System)

        New Function
      • Image stabilization: Hybrid method of OIS 2-axis + roll direction correction D.I.S.S.
      • Menu switching: 4 values
      • (OFF / OIS / Hybrid (Stable) / Hybrid (Pan/Tilt)) and D.I.S.S.
      • On/Off selectable

        Image Resolution
      • JPEG (MJPEG), H.264: 3840x2160, 1920x1080, 1280x720, 640x360, 320x180
      • H.265: 3840x2160, 1920x1080, 1280x720, 640x360
      • High Bandwidth NDI®: 3840x2160, 1920x1080, 1280x720
      • NDI®|HX Version 2: 1920x1080, 1280x720

    • Item Includes:

      • 1x Panasonic AW-UR100 Outdoor-ready IP65 NDI 4K60p Integrated PTZ Camera with 24x Optical Zoom
