Panasonic PT-MZ11KLW 11000-Lumen WUXGA Resolution 3LCD Laser Video Projector - No Lens - White

ITEM #: PAN-PT-MZ11KLWUB MFG #: PT-MZ11KLWU8

Primary Image
  • Product Image Thumbnail 1 of 3
  • Product Image Thumbnail 2 of 3
  • Product Image Thumbnail 3 of 3
Free Shipping with $49 Minimum Order

List Price:

$20,799.00

Our Price:

$13,995.00

Availability: Usually Ships in 5-14 Days.
Please Email, Chat or Call (800) 522-2025 for Detailed Delivery Info
iAvailability Description Popup


PT-MZ11KLWU8 - Overview

Long-Life Energy-Saving Design Minimizes Problems

The Panasonic PT-MZ11KLWUB, without lens is the industry's first 20,000 lm-class projector to deliver full brightness on AC 100V - 240V power, eliminating need to install a high-voltage power supply. It supports NFC function optional lenses including the ET-EMU100 Ultra-Short Throw Zoom Lens and preactivated upgrade kits for Geo Pro (lens and kits sold separately).

Detail Clarity Processor 4 Improves Dimensionality and Sharpness
Panasonic Connect's unique image quality correction circuitry reproduces details more clearly and sharply. It analyzes video signal frequencies in each scene and adjusts for optimal sharpness based on information extracted from the signal. Compared to conventional image processing technology, this system reproduces images with an even more natural and three-dimensional feel.

Supports 4K Signal Input
Uncompressed 4K/60p input signals1 are supported via HDMI or DIGITAL LINK. Since no external devices such as converters are required, 4K signals can be processed smoothly. This eliminates the need for re-encoding when the projector is used with other 4K-compatible equipment, making projection with 4K signals simple and efficient.

Compatible with Ultra-Short-Throw Zoom Lens for Space-Saving Installation
ET-EMU100 Ultra-Short-Throw Zoom Lens (sold separately) has a throw ratio of 0.330-0.353:1 and a screen size range of 100" - 400", and enables large-screen projection even from tight installation spaces. With no gap (offset area) between the ceiling and the screen, ET-EMU100 eliminates need for adjustment and expands the range of visual expression by supporting the zoom function despite its ultra-short focus.

  • Features:

    • Supports 21:9 input signals
    • Supports Art-Net DMX, PJLink, Crestron Connected V2, Crestron XiO Cloud, Extron XTP and IPv61
    • Compatible with Multiple PJ Firmware Batch Update Tool
    • Direct Power Off function
    • Scheduling function
    • Presentation support system
    • Free 360° installation
    • Quick Startup and Quick Off
    • Multi-unit Brightness and Color Control function
    • Multi-Screen Support System
    • DICOM Simulation Mode
    • Waveform monitoring function

  • Specifications:

    • Projector Type: LCD projectors
    • Display Method: Transparent LCD panel (3x, R/G/B)
    • Display Device:
      - Panel Size: 1" (25.4mm) diagonal (16:10 aspect ratio)
      - Drive Method: Active matrix method
      - Number of Pixels: 2,304,000 (1920 x 1200 pixels)
    • Light Source: Laser diode
    • Light Output: 11,000 lm
    • Light Output (ANSI): 11,000 lm
    • Time Until Light Output Declines to 50%:
      - Normal: 20,000 hours
      - Quiet: 20,000 hours
    • Resolution: WUXGA (1920 x 1200 pixels)
    • Contrast Ratio (typ.): 3,000,000:1 (Full On/Full Off )(When [PICTURE MODE] is set to [DYNAMIC] and [DYNAMICCONTRAST] set to [3].)
    • Screen Size (diagonal): 80" - 600" (2.03m - 15.24m), 100" - 400" (2.54m - 10.16m) with ET-EMU100, 80" - 500" (2.03m - 12.70m) with ET-EMT800, 16:10 aspect ratio
    • Center-to-Corner Zone Ratio: 85%
    • Lens: Optional (no lens included with this model)
    • Lens Shift:
      - Vertical (from center of screen): ±60% (+50%, -20% with ET-EMU100, ±40% with ET-EMW200, ±50% with ET-EMW300)(powered)
      - Horizontal (from center of screen): ±20% (±19% with ET-EMW200) (powered)
    • Keystone Correction Range:
      - Vertical: ±45° (±5° with ET-EMU100, ±14° with ET-EMW200/ET-EMW300, ±22° with ET-EMW400/ET-EMW500),
      - Horizontal: ±40° (±0° with ET-EMU100, ±8° with ET-EMW200/ET-EMW300, ±15° with ET-EMW400/ET-EMW500).
      - When [VERTICAL KEYSTONE] and [HORIZONTAL KEYSTONE] are used simultaneously,correction cannot be made exceeding a total of 55°.
    • Installation: Ceiling/floor, front/rear, free 360° installation
    • Terminals:
      - SDI IN: 1x BNC 3G/HD-SDI input
      - HDMI IN: 2x HDMI 19-pin (Compatible with HDCP 2.3, Deep Color, 4K/60p signal input), CECsupported
      - SERIAL/MULTI-PROJECTOR SYNC IN: 1x D-sub 9-pin (female) for external control (RS-232C compliant)
      - SERIAL/MULTI-PROJECTOR SYNC OUT: 1x D-sub 9-pin (male) for link control (RS-232C compliant)
      - REMOTE 1 IN: 1x D-sub 9-pin (female) for external control (parallel)
      - REMOTE 2 IN: 1x M3 for wired remote control
      - REMOTE 2 OUT: 1x M3 for link control (for wired remote control)
      - DIGITAL LINK IN/LAN: 1x RJ45 for network and DIGITAL LINK connection (video/network/serial control)(HDBaseT compliant), 100Base-TX (Compatible with PJLink [Class 2], Art-Net, HDCP2.3, Deep Color, 4K/60p signal input)
      - LAN: 1x RJ45 for network connection, 10Base-T, 100Base-TX (Compatible with PJLink [Class2], Art-Net)
      - DC OUT: 1x USB connector (Type A) for power supply (Output: 5V/2A)
      - USB TYPE A: 1x USB connector (Type A) for optional AJ-WM50 Series Wireless Module, for USB memory
    • Power Supply: AC 100V - 240V, 50/60Hz
    • Maximum Power Consumption: 615W (6.3A - 2.7A) (630VA)
    • On-Mode Power Consumption (Operating Mode - Normal):
      - 540W (AC 100V - 120V)
      - 520W (AC 200V - 240V)
    • On-Mode Power Consumption (Operating Mode - Quiet):
      - 360W (AC 100V - 120V)
      - 340W (AC 200V - 240V)
    • Cabinet Materials: Molded plastic
    • Filter: Included
    • Estimated Filter Maintenance Cycle: approx. 20,000 hours
    • Operation Noise:
      - Normal: 35dB
      - Quiet: 30dB
    • Dimensions (WxHxD): 25.59" x 7.28" x 17.32" (650mm x 185mm x 440mm)
    • Dimensions (WxHxD)(excluding feet andprotrusions, with feet at shortest position): 25.59" x 8.31" x 17.32" (650mm x 211mm x 440mm)
    • Weight: 80lbs (36.3kg)
    • Body Color: White

  • Item Includes:

    • 1x PT-MZ11KLWUB

  • Warranty:

    • 3 Year Limited Warranty
