Palmer Audio PGA04L16 Speaker Simulator with Loadbox 16 Ohms

ITEM #: PLM-PGA04L16 MFG #: PGA04L16

Primary Image
  • Product Image Thumbnail 1 of 2
  • Product Image Thumbnail 2 of 2

This item is no longer available.
Ask a Markertek Expert if you need assistance finding an appropriate substitute.

(800) 522-2025Email

Items similar to the PLM-PGA04L16

PGA04L16 - Overview

Special DI box with loadbox for guitars. The integrated load resistor permits tube amplifiers up to approximately 120 W to be connected to the PGA04, bypassing a loudspeaker. A jack socket (unbalanced) and balanced XLR connector are available for direct pickup of the signal. The extensive filter section provides for a realistic simulation of classic guitar loudspeaker sounds.

  • Features:

    • Speaker Simulator + 16 Ohm Loadbox + Made in Germany + DI Box

  • Specifications:

    • Product type: speaker simulator
    • Type: passive
    • Channels: 1
    • input type: unbalanced
    • Inputs: 1
    • input connectors: 6.3 mm Jack
    • output type: balanced, unbalanced
    • Outputs: 2
    • output connectors: 6.3 mm Jack, XLR
    • output impedance: 10 k (6.3 mm Jack), 600 (XLR) Ohm(s)
    • controls: fullrange volume, high, low, high cut, colour, filter volume
    • Display: max. load
    • dummy load: yes
    • dummy load impedance: 16 Ohm(s)
    • max. load: 100 W
    • voicing filter: yes
    • power attenuator: no
    • transformer balanced inputs: no
    • transformer isolated outputs: yes
    • cabinet material: sheet steel
    • Cabinet / Housing surface: powder coated

  • GTIN:

    4049521087875
