RCF SUB9007-AS Active Subwoofer with 4-Inch Voice Coil and Two 21-Inch Woofers

SUB9007-AS - Overview

• Features:

  • 7200 Watt Peak power - 3600 Watt RMS
  • 141 dB max SPL
  • 20Hz - 400Hz frequency response
  • Two 21" Woofer
  • DSP controlled Input section with selectable presets
  • Delay control
  • Integrated mechanics for multiple configurations with HDL 50-A 4k, HDL 20-A, HDL 10-A
  • RDNet remote and control
  • Baltic birch tour grade cabinet


• Specifications:

  • Frequency Response: 20 Hz - 400 Hz
  • Max SPL @ 1m: 141 dB
  • Woofer: 2x 21" neo, 4.0" v.c
  • Input Signal: bal/unbal
  • Input Connectors: XLR, RDNet Ethercon
  • Output Connectors: XLR, RDNet Ethercon
  • Input Sensitivity: +4 dBu
  • Hi-Pass Frequencies: 25Hz, 35Hz
  • Low-Pass Frequencies: Variable from 50Hz to 400Hz
  • Protections: Thermal, RMS
  • Limiter: Fast Limiter
  • Controls: Gain, EQ, Xover, Phase switch, Output Delay Settings, Cardiloid.
  • RDNet: Onboard
  • Total Power: 7200 W Peak, 3600 W RMS
  • Low Frequencies: 7200 W Peak, 3600 W RMS
  • Cooling: Convection
  • Connections: Powercon IN/OUT
  • Safety Agency: CE compliant
  • Cabinet/Case Material: Baltic birch plywood
  • Hardware: Mounting points, 2x M20
  • Handles: 8 side
  • Pole Mount/Cap: M20 thread
  • Grille: Steel
  • Color: Black
  • Height: 27.87" (708 mm)
  • Width: 46.77" (1188 mm)
  • Depth: 30.91" (785 mm)
  • Weight: 211.64 lb (96 kg)
  • Package Height: 29.92" (760 mm)
  • Package Width: 32.48" (825 mm)
  • Package Depth: 44.69" (1135 mm)
  • Package Weight: 242.51 lbs (110 kg)
