Bellari PA253 Stereo Audio Power Amplifier - 50W - 3Hz to 43kHz

ITEM #: RLS-PA253 MFG #: PA253

Primary Image
  • Product Image Thumbnail 1 of 2
  • Product Image Thumbnail 2 of 2
Free Shipping with $49 Minimum Order

List Price:

$399.00

Our Price:

$299.00

Availability: Typically Ships in 3-10 Business Days
iAvailability Description Popup


    PA253 - Overview

    At every design stage we focused on one thing, sound quality

    The Bellari PA253 is a stereo power amplifier designed for excellent sound quality.

    All Bellari products are hand built in Salt Lake City, Utah by people who care about high quality music. No surface mount parts are ever used at Bellari. The chassis is made in Salt Lake City, UT. The steel sheets are cut, bent, formed, and finished all by US labor. After that process the steel is powder coated to a high gloss red, also done by US labor.

    The chassis is silk-screened and the PCB's assembled at Bellari's Salt Lake City factory. Bellari flow solders the PCB's and sends them to post flow assembly where they add the fragile components soldering them in by hand. Bellari tests the PCB's and send them to mechanical assembly were the PA253 is completed then tested again. The boxes that Bellari uses are made in a facility just a few miles from them. Even the out bound shipping boxes, biodegradable peanuts and printing materials are made in the US.

    • Features:

      • Designed for Home Listening
      • Powder-Coated Steel Chassis
      • Hand-Soldered Components
      • Made in the USA

    • Specifications:

      • DC Output Voltage: ± 0 mV
      • S/N Ratio: >100 dB unweighted
      • Crosstalk: < - 95 dB from 20Hz to 20kHz
      • THD: .015% @ 1KHz
      • Phase Shift: 0 Deg.
      • Power Efficiency: 90%
      • Power Stage Gain: 32.6 dB @ 8 ohms 31.4 dB @ 4 ohms
      • Input Impedance: 10k - 5Hz to 100kHz
      • Output Impedance: < 0.32 ohms from 20 Hz to 20 kHz (Measured under 8 ohms)
      • Dampening Factor: > 100
      • Frequency Response: 3Hz to 43kHz
      • Volume Max Gain: 33.7 dB no load
      • Rise Time: < 0.9 æs
      • Slew Rate: > 20 V/æs, peak-peak
      • Nominal Output Power: 50 watts RMS @ 4 ohms 42 watts RMS @ 8 ohms
      • Connection Output Impedance: 4 to 8 ohms speakers
      • PWR: 24 VDC @ 4A (KS100DU) Included.
      • Size (WxDxH): 5.5 x 3.5 x 1.25"

    • Item Includes:

      • 1x PA253 proudly made in USA
      • 1x Owner's Manual
      • 1x 24V power supply KS100DU

    • GTIN:

      0675889002539
