Ross XPN-1RU-12G-M9 Xpression 1RU Real-Time Motion Graphics Engine - HD-SDI Chassis - 12G-SDI

ITEM #: ROSS-XPN1RU12GM9 MFG #: XPN-1RU-12G-M9

Primary Image
  • Product Image Thumbnail 1 of 3
  • Product Image Thumbnail 2 of 3
  • Product Image Thumbnail 3 of 3
Ross Video
Free Shipping with $49 Minimum Order

Our Price:

$18,980.00

Add to Wish ListLeasing Options
Availability: In Stock - Ships Factory Direct, Typically in 6 Business Days.
Please Email, Chat or Call (800) 522-2025
iAvailability Description Popup
  • Shipped to USA (50 states) only.
  • Special Order Item: non-cancelable, non-returnable, non-refundable.
Report Lower PriceLarge Quantity Quote

XPN-1RU-12G-M9 - Overview

The Ross XPN-1RU-12G-M9 Xpression Motion Graphics Engine allows you to build stunning visuals and transform your data into compelling stories with the most powerful real-time motion graphics system on the market today. Every day, visual storytellers in news, sports, and live entertainment use XPression to enhance their stories and engage their viewers. XPression equips your team with the tools to build on-brand, data-driven 2D & 3D graphics and animations and automatically composites them in any live video format, in real time. Whether you need graphics for news, sports, entertainment, branding, live events, virtual sets, or augmented reality, there's an XPression system that's right for you.

  • Specifications:

    • Chassis: 1RU Chassis (rackmount)
    • Power Supply: 2x 675W power supplies (redundant)
    • Voltage Range: 100V - 240VAC
    • Input Current: 3.7A - 7.4A
    • Power Consumption @ 115VAC:
      • Idle: 83.416W
      • Max: 454.3W
    • Fan Noise: Between 36dB - 46dB
    • System Drive: 465G (2x 500GB 3D NAND 2.5" SSD RAID1)
    • Media Drive: 3.8TB (2x 4TB 3D NAND 2.5" SSD in RAID1)
    • CPU: Intel Xeon W5-2445, 10-Core, 26.25MB Cache, 2.70GHz, 4.0 GHz Turbo
    • Memory: 64GB (4x16GB) 4800MT/s DDR5 RDIMM with ECC
    • GPU: NVIDIA RTX 4000 Ada 20GB GDDR6, 4x DisplayPort 1.4a
    • Video I/O: HD-SDI or Quad-link SDI Matrox DSXLE4/44/100, NDI
    • O/S: Microsoft Windows 11 Professional for Workstation
    • Video I/O:
      • 4x HD-BNC Out
      • 4x Bi-directional HD-BNC for up to 4 Channels (Video/Key Pair) of 1080p or 1 Channel Quad-Link UHD Output
      • NDI
    • Audio: Embedded Audio Only
    • Reference: 1x Analog Black Burst (Bi-Level Sync) or Tri-Level Sync input
    • Ethernet Control:
      • 1x RJ45 1G Ethernet Port
      • 1x RJ45 10G Ethernet Port
    • Serial:
      • 1x RS-232 Port
      • 2x P/S2 Ports
    • GPI: Unlimited RossTalk Smart GPI over TCP/IP
    • USB:
      • Front Panel:
       - 2x USB 3.1 (Type A)
       - 2x USB Type C
      • Rear Panel: 2x USB 3.1 (Type A)


  • Item Includes:

    • 1x Rackmount Kit - Slide rails, handles, and mounting hardware
    • 1x Keyboard - Standard USB Windows PC Keyboard
    • 1x Mouse - USB 2-button mouse
    • 1x Security Key Software - Either USB Hardware License or Software-based Product Key provided with software purchased separately.
