Smart-AVI DFX-XT-TX 4K HDMI USB 2.0 and Audio KVM via Single Mode Dual Fiber Transmitter - Up to 6.2 Miles

ITEM #: SAVI-DFX-XT-TX MFG #: DFX-XT-TX

Primary Image
  • Product Image Thumbnail 1 of 3
  • Product Image Thumbnail 2 of 3
  • Product Image Thumbnail 3 of 3
Free Shipping with $49 Minimum Order

Our Price:

$649.00

Availability: Ships Factory Direct, Typically in 3-10 Business Days
iAvailability Description Popup


    DFX-XT-TX - Overview

    The Smart-AVI DFX-XT-TX is a Single Head HDMI (3840 x 2160), USB 2.0, USB keyboard-mouse and stereo audio extender, sending signals up to 10 km (6.2 miles) away over a single conventional and inexpensive a dual fiber cable. This new technology is superior to older HDMI extenders that require a special dual fiber shielded cable to go a short distance.

    The DFX-XT is the first extender on the market to feature 3840 x 2160, USB 2.0 and full KVM extension on one cohesive system and is optimized for Full HD monitors with crystal-clear picture; excellent for detail driven work.

    The DFX-XT extends keyboard-mouse signals for remote workflow management and offers uninterrupted emulation from the user's transmitter unit. This uninterrupted emulation prevents accidental disconnection or deactivation issues during mission critical operations. The DFX-XT's unparalleled KVM extension technology makes it the perfect solution for extending servers in applications ranging from data processing to interactive conferencing.

    Audio and Visual Recording
    For users in the recording arts, maintaining the utmost in signal and recording fidelity is an absolute necessity. For video recording, it is often important that no unsightly computers are visible. Similarly, audio engineers must keep noisy computers away from the rooms where recording happens to ensure the final product sounds professional. In both such instances, the DFX-XT gives users the ideal way to keep their servers or computers away from areas that audio or video recording is being done, ensuring a better final product.

    • Features:

      • Extends HDMI up to 10 km (6.2 miles) in the Single Mode and up to 500 m (1640.42 feet) in the Multi Mode from the source
      • HDCP Support
      • Supports up to 3840 x 2160 digital video resolution @ 30 Hz
      • USB Keyboard and Mouse extension
      • Uncompressed Video
      • External power adapter for transmitter and receiver unit
      • Supports Stereo Sound
      • Compatible with Windows, Mac and Linux Operating Systems
      • Transparent USB 2.0 extension

    • Specifications:

      • Video
      • Format: HDMI2.0
      • Video Resolution:
        - Resolution: high definition 3840 x 2160
        - Color Depth: 24-bit color depth
        - Latency: less than 1 ms
      • Video Bandwidth: Single-link 340 MHz (10.2 Gbps)
      • Input Interface: (1) HDMI 19-pin (female)
      • Output Interface: (1) HDMI 19-pin (female)
      • Max Output Distance: Up to 20 f
      • Equalization: Automatic
      • Input TMDS Signal: 1.2 Volts [peak-to-peak]
      • Input DDC Signal: 5 Volts [peak-to-peak, TTL]
      • Data Rate: 1.65 Gbps per color

        Audio
      • Format: Stereo
      • Input Interface: 3.5 mm Jack Socket (female)
      • Output Interface: 3.5 mm Jack Socket (female)

        USB
      • Input Interface (TX): (1) USB Type B
      • Keyboard and Mouse: Keyboard and mouse emulation

        System
      • Fiber Interface & Type: Single-Mode Fiber
      • Cable Requirements: Dual Fiber
      • Maximum Length:
        - Single mode: 10 km (6.2 miles)
        - Multi mode: 500 m (1640.42 feet)

        Other
      • Power: 100-240 VAC/ 5VDC @ 3A/15W
      • Dimensions(WxHxD): 7.8 x 1.15 x 3.65 In (198.12 x 29.21 x 92.71 mm)
      • Weight: .5 lbs (.23 kg)
      • Approvals: UL, CE, ROHS Compliant
      • Operating Temp.: +32 to 104 °F (0-40 °C)
      • Storage Temp.: 4 to 140°F (-20 to +60°C)
      • Operating Humidity: 20% to 80% (non condensing)
      • Storage Humidity: Up to 95% (No Condensation)
      • Compliance EMC: FCC (Class A), CE (Class A), ICES-003
      • Environmental Compliance: RoHS2 (CE)

    • Item Includes:

      • 1x DFX-XT-TX Unit
      • 1x Power Adapter
      • 1x User Manual

    • Warranty:

      • 1 Year Warranty


    DFX-XT-TX - Required Accessories
