MXA320B - Overview

The Shure MXA320 is the next evolution of Shure's table array microphone that provides high quality audio capture and flexible configuration for AV conferencing environments including boardrooms, huddle rooms and conferencing rooms. It features Steerable Coverage Technology with onboard IntelliMix DSP, streamlined deployment with Designer System Configuration Software and intuitive remote management via ShureCloud, all housed in a familiar, compact, low-profile design.

How It Works
The MXA320 integrates smartly into any meeting space. Boardrooms. Huddle rooms. Conferencing rooms. Thanks to Steerable Coverage technology, speech is captured accurately and intelligibly. With onboard IntelliMix DSP that includes acoustic echo cancellation (AEC), speech gating threshold, and noise reduction algorithms, the MXA320 provides crystal clear video conferencing audio for all participants.

Why It's Better
Onboard IntelliMix DSP with Acoustic Echo Cancellation, Speech Gating Threshold, and Noise Reduction, to deliver crystal clear audio in any space. Steerable Coverage technology provides highly directional audio capture, configured visually with Designer System Configuration Software, allowing MXA320 coverage to be easily viewed alongside other Microflex Ecosystem products in the room.

  • Features:

    • Certified for use with Microsoft Teams and Zoom; compatible with other popular collaboration tools
    • Remote device management, real-time device monitoring of device status and firmware updates with ShureCloud.
    • Programmable LED light ring with configurable colors and brightness control
    • Supports standards-based security protocols to manage access and protect data, including 802.1x, secure boot/storage, and AES encryption for control and audio data.
    • LED Mute Sync with leading software conferencing platforms including Microsoft Teams, and Zoom Rooms (when used with IntelliMix P300, IntelliMix Room or ANIUSB MATRIX)
    • Remote device management, real-time device monitoring of device status, and performance with ShureCloud.
    • Audio capture can be configured visually in Shure's Designer software, allowing MXA320 coverage to be easily viewed alongside other Microflex Ecosystem products in the room.
    • Connectivity with Dante Audio Networking, standard PoE (class 0), and Control carried on single Ethernet cable.

  • Specifications:

    • Connector Type: RJ45 (for Ethernet)
    • Power Requirements: PoE Class 0
    • Weight: 0.8lbs (362g)
    • Product Dimensions: 1.4" x 5.3" x 5.3" (3.6cm x 13.4cm x 13.4cm)
    • Control Software: Shure Designer
    • Cable Requirements: Cat5e or higher
    • Operating Temperature Range: 20°F - 104°F (-6.7°C - 40°C)
    • Frequency Response (-3dB): 100Hz - 20kHz

  • Item Includes:

    • 1x Black Table Array Microphone
    • 1x Cable-exit plug
    • 1x Mounting tube wing nut
    • 1x Rubber Isolation Ring
    • 4x Nylon cable ties
