Shure PA805DB-RSMA Dual-Band Passive Directional Antenna for GLX-D+ Wireless - Z3 2.4 & 5.8GHz

PA805DB-RSMA - Overview

• Features:

  • Improved wireless reception: 8dB of passive directional antenna gain
  • Improved rejection of interference from 2.4 and 5.8GHz sources: 24dB front-to-back ratio for improved rejection of off-axis signals
  • Can be painted with non-metallic paint to match mounting surface
  • Includes 3m RSMA cable


• Specifications:

  • Frequency Range: 2.39 to 2.51 GHz and 5.0 to 6.0 GHz
  • Antenna Gain:
  • @ 2.45 GHz, typical: 6.2 dBi
  • @ 5.785 GHz, typical: 8.4 dBi
  • 3 dB Horizontal Beam Width
  • @ 2.45 GHz, typical: 109 degrees
  • @ 5.785 GHz, typical: 64 degrees
  • 3 dB Vertical Beam Width
  • @ 2.45 GHz, typical: 61 degrees
  • @ 5.785 GHz, typical: 53 degrees
  • Polarization: Linear
  • Impedance: 50 Ω
  • Voltage Standing Wave Ratio (VSWR)
  • 2.4 - 2.5 GHz < 1.5 (< 1.3, typical)
  • 5.0 - 6.0 GHz < 2.5 (< 2, typical)
  • Connector Type: Reverse SMA
  • Dimensions (H x W x D): 4.13 x 6.45 x 1 in. (105 x 164 x 27.5 mm) with mounting accessories,
  • Weight: 0.15 lb/2.5 oz (56.7 g) with mounting accessories


• Item Includes:

  • 1x PA805DB-RSMA Dual-Band Passive Directional Antenna for GLX-D+ Wireless (2.4, 5.8 GHz)
  • 1x Mounting Assembly with Connecting Cable
  • 1x LMR240 Cable (10ft)


• Warranty:

  • 2 Year


• GTIN:

  0042406694933
