NTI SM-32x16-15V-LCD 32x16 VGA Video Matrix Switcher
    Questions? Ask a Markertek Expert:
    800-522-2025 Email

    NTI SM-32x16-15V-LCD 32x16 VGA Video Matrix Switcher

    Item #: SM-32X16-15V-LCD   •   MFG #: SM-32X16-15V-LCD


    List Price:$6,165.00
    Our Price:$5,785.00

    free ship
    Availability: Direct Ship From Manufacturer
    Item ships directly from the manufacturer. Normal delivery time is 2-7 business days and is subject to manufacturer availability. Need it sooner? Call 800-522-2025, or email Customer Service for expedited delivery options.
    • Special Order Item: non-cancelable, non-returnable, non-refundable.
    • 2 - 7 Day Normal Delivery Time - Faster Shipping Options at Checkout or Call Us.



    The VEEMUX® SM-nXm-15V-LCD video matrix switch routes video from many computers to multiple displays (projectors, monitors, etc.) This switch can drive standard VGA cables, thus eliminating the need for external interfaces and coax cable connections via BNC connectors.

    Signals from a range of input sources can be distributed to various output devices, in essence creating a "matrix" pattern of interconnection possibilities. A single computer video output can be routed to one or more monitors. Each image will be as crisp and clear as if directly connected to the original source. Each video output is buffered from each input, insuring signal integrity throughout the system.

    • Features

      • Configure and control the switch through Ethernet, serial port or front panel buttons.
      • Control switching via optional Infrared remote control.
      • NTI Switch Control Program with Graphical User Interface (GUI control) is included with the product.
      • Equipped with Liquid Crystal Display (LCD) for front panel operation.
      • Switch VGA video directly.
      • Each output provides one video signal.
      • Each input can be independently connected to any or all outputs.
      • Video bandwidth is 200 MHz or greater.
      • Supports 1920x1200 video resolution at a refresh rate of 85 Hz.
      • All units pass vigorous testing with 24 hr minimum burn in, heat testing, and load test of all ports.
      • Digital Signage
      • Classrooms.
      • Boardrooms.
      • Trade shows.
      • Conference and entertainment facilities.
      • Courtrooms.
      • Command centers.
      • Control rooms.
