StarTech PEX433WAC11 AC600 Wireless-AC Network Card - PCIe / Dual Band 2.4GHz/5GHz

ITEM #: ST-PEX433WAC11 MFG #: PEX433WAC11

Primary Image
  • Product Image Thumbnail 1 of 5
  • Product Image Thumbnail 2 of 5
  • Product Image Thumbnail 3 of 5
  • Product Image Thumbnail 4 of 5
  • Product Image Thumbnail 5 of 5
Free Shipping with $49 Minimum Order

List Price:

$64.99

Our Price:

$56.23

Availability: Typically Ships in 3-10 Business Days
iAvailability Description Popup


    PEX433WAC11 - Overview

    Upgrade your desktop PC or server to powerful 802.11ac wireless networking. This StarTech PEX433WAC11 AC600 network card fits easily into a PCI Express expansion slot to give you dual-band wireless-AC connectivity with speeds up to 433 Mbps.

    Add dual-band Wireless-AC connectivity
    This PEX433WAC11 wireless-AC adapter lets you add dual-band wireless-AC connectivity to a desktop computer through a PCIe slot. Ideal for your office or home environment, the PCIe Wi-Fi® adapter provides a wireless range of up to 100 feet (30m), when paired with an 802.11ac router. It's a cost-effective solution for adding or upgrading to the latest 802.11ac dual-band wireless networking.

    The Wi-Fi adapter supports data rates of up to 433 Mbps at 5 GHz, and 150 Mbps at 2.4 GHz. Two detachable external antennas enhance reception and provide more reliable connections.

    Versatile use
    The versatile USB Wi-Fi adapter gives you dual-band 2.4/5 GHz support, so you can connect easily to the less congested 5GHz wireless network to enjoy lag-free HD video streaming, online gaming, file transfers or other bandwidth-intensive applications. The WMM Quality of Service (QoS) feature quickly prioritizes video streams, Internet calls and online gaming.

    This network adapter has a 1T1R (1 transmitter, 1 receiver) antenna design and features two detachable external antennas (dual-band 3dBi). To integrate easily with all of your networking devices, the wireless network adapter is backward compatible with 802.11a/b/g/n networks.

    Quick and easy installation
    The network card is easy to install in the PCI Express slot on your standard or small form-factor computer. It comes equipped with a standard profile bracket, and includes a low-profile bracket that you can swap in to mount the card in smaller or space-constrained systems.

    The PEX433WAC11 is backed by a StarTech 2-year warranty and free lifetime technical support.

    • Features:

      • Wireless AC600 compatible with speeds up 433Mbps (5GHz) and up to 150Mbps (2.4GHz)
      • Dual band 2.4 / 5GHz support (802.11ac is 5 GHz only)
      • Compliant with 802.11 ac/a/b/g/n networks
      • Single antenna (1T1R) for transmitting and receiving
      • Dual external (detachable) dual-band 3dBi antennas
      • PCI Express host interface
      • Wireless security with 64/128bit WEP, WPA, WPA2 and TKIP/AES
      • Supports WMM Quality of Service and WMM-PS
      • Supports Soft AP mode
      • Configured with standard profile bracket, low profile and half-height bracket included

    • Specifications:

      • Hardware
      • Antenna Configuration: 1T1R
      • Bus Type: PCI Express
      • Card Type: Standard Profile (LP bracket incl.)
      • Chipset ID: Realtek - 8821AE
      • Industry Standards: IEEE 802.11ac, IEEE 802.11n, IEEE 802.11g, IEEE 802.11a, IEEE 802.11b
      • Interface: Wireless Ethernet

        Performance
      • Auto MDIX: No
      • Bandwidth: 20/40/80 MHz
      • Frequency: 2.4G/5.8G-Dual band
      • Frequency Range: 2.412~2.462 GHz, 5.180~5.825 GHz
      • Full Duplex Support: No
      • Max Distance: 30 m / 100 ft
      • Maximum Data Transfer Rate: 433 Mbps (5 GHz)
      • 150 Mbps (2.4 GHz)
      • Security Features: WEP Data Encryption
      • WPA and WPA2-PSK Data Encryption
      • TKIP/AES

        Connector(s)
      • Connector Type(s): 1 - PCI Express x1
      • 2 - RP-SMA (Coax, Reverse Polarity SubMiniature A)

        Software
      • OS Compatibility: Windows® 10 (32/64bit), 8 / 8.1 (32/64), 7 (32/64), XP(32/64)
      • Windows Server® 2012, 2008 R2,
      • SPECIAL NOTES / REQUIREMENTS
      • System and Cable Requirements: Available PCI express expansion slot

        Indicators
      • LED Indicators: 1 - Link/Activity

        Environmental
      • Humidity: 0% ~ 90% RH
      • Operating Temperature: 0°C to 60°C (32°F to 140°F)
      • Storage Temperature: 10°C to 70°C (50°F to 158°F)

        Physical Characteristics
      • Product Height: 0.9 in [2.2 cm]
      • Product Length: 4.8 in [12.1 cm]
      • Product Width: 3.8 in [97 mm]
      • Weight of Product: 1.7 oz [49 g]

        Packaging Information
      • Package Height: 1.3 in [32 mm]
      • Package Length: 6.6 in [16.8 cm]
      • Package Width: 5.5 in [14 cm]
      • Shipping (Package) Weight: 5.5 oz [157 g]

    • Item Includes:

      • 1x PCI Express AC600 Wireless-AC network adapter
      • 1x Detachable External Antenna
      • 1x Driver CD
      • 1x Low Profile Bracket
      • 1x Quick Start Guide

    • Warranty:

      • 2 Years

    • GTIN:

      0065030863513
