APC SURTD6000RMXLP3U Smart-UPS RT 6000VA RM 208V to 208/120V

ITEM #: SURTD6000RMXLP3U MFG #: SURTD6000RMXLP3U

Primary Image
  • Product Image Thumbnail 1 of 2
  • Product Image Thumbnail 2 of 2
Free Shipping with $49 Minimum Order

List Price:

$10,620.00

Our Price:

$7,675.00

Availability: Typically Ships in 3-10 Business Days
iAvailability Description Popup
  • Shipped truck freight.


SURTD6000RMXLP3U - Overview

Peace of mind that comes with full equipment compatibility and reliability of a leader
The APC SURTD6000RMXLP3U Smart UPS Provides pure sine wave output which is recommended by server manufacturers using active power factor corrected (PFC) power supplies. Safety agency tested and approved means that you can deploy Smart-UPS with confidence that they meet or exceed the industry's most rigorous standards.

Low operating and maintenance costs with proven reliability and intelligent battery management .
Intelligent battery management, pioneered by APC, maximizes battery performance and life through intelligent, precision temperature compensated charging. Automatic self tests insure battery reliability and warn customers in advance of battery replacement. Convenient, easy to connect, hot-swappable battery modules provide battery replacement without powering down.

Avoids costly power problems by keeping your IT equipment and data protected and available .
Network grade power conditioning protects from damaging surges and disruptive noise. The double conversion architecture provides tight voltage regulation, frequency regulation ,and zero transfer time to battery during power events.

Save time with easy and convenient remote/network accessibility.
Network manageable via serial, USB or Ethernet. Includes Powerchuter Software for convenient monitoring and control, safe operating system shutdown, and innovative energy management capabilities.

  • Features:

    • High density, double-conversion on-line power protection with scalable runtime
    • Includes: CD with software, Rack mounting support rails, Removable support feet, Smart UPS signalling RS-232 cable, User manual

  • Specifications:

    • Output
    • Max Configurable Power (Watts): 4.2kWatts / 6.0kVA
    • Output Voltage Note: Configurable for 208 or 240 nominal output voltage
    • Efficiency at Full Load: 90.0 %
    • Output Voltage Distortion: Less than 2 %
    • Output Frequency (sync to mains): 50/60 Hz +/- 3 Hz user adjustable +/- 0.1 Hz Sync to mains
    • Other Output Voltages: 240
    • Load Crest Factor: 3 : 1
    • Topology: Double conversion online
    • Waveform type: Sine wave
    • Bypass: Internal bypass (automatic and manual)

      Input
    • Input frequency: 50/60 Hz +/- 5 Hz Auto-sensing
    • Input voltage range for main operations: 156 - 236, 85 - 136 AdjustableV
    • Number of Power Cords: 1
    • Efficiency at Full Load: 90.0 %
    • Other Input Voltages: 240

      Batteries & Runtime
    • Battery type: Lead-acid battery
    • Included Battery Modules: 2
    • Typical recharge time: 2.5hour(s)
    • Replacement Battery: APCRBC140
    • Expected Battery Life (years): 3 - 5
    • RBC Quantity: 1
    • Battery Charge Power (Watts): 382 Watts
    • Extendable Run Time: 1

      Communications & Management
    • Interface Port(s): RJ-45 10/100 Base-T, SmartSlot
    • Pre-Installed SmartSlotT Cards: AP9631
    • Control panel: LED status display with load and battery bar-graphs and on line : on battery : replace battery : overload
      and bypass indicators
    • Audible Alarm: Alarm when on battery : distinctive low battery alarm : overload continuous tone alarm
    • Emergency Power Off (EPO): Yes

      Physical
    • Maximum Height: 5.12inches (130MM, 13.0CM)
    • Maximum Width: 17.01inches (432MM, 43.2CM)
    • Maximum Depth: 25.98inches (660MM, 66.0CM)
    • Net Weight: 128.0lbs. (58.06KG)
    • Shipping weight: 159.0lbs. (72.12KG)
    • Shipping Height: 13.66inches (347MM, 34.7CM)
    • Shipping Width: 23.74inches (603MM, 60.3CM)
    • Shipping Depth: 38.58inches (980MM, 98.0CM)
    • Color: Black
    • Units per Pallet: 6.0


SURTD6000RMXLP3U - Required Accessories
