Telestream WCG3-HD-HDMI-510 Wirecast Gear 3 HD HDMI Professional Streaming Device

ITEM #: TEL-WCG3HDHDM510 MFG #: WCG3-HD-HDMI-510

Primary Image
  • Product Image Thumbnail 1 of 5
  • Product Image Thumbnail 2 of 5
  • Product Image Thumbnail 3 of 5
  • Product Image Thumbnail 4 of 5
  • Product Image Thumbnail 5 of 5
Free Shipping with $49 Minimum Order


Availability: Sold Out
iAvailability Description Popup


    WCG3-HD-HDMI-510 - Overview

    The Telestream WCG3-HD-HDMI-510 Wirecast Gear 3 is an HD HDMI professional streaming device. With the Wirecast Gear 3's 4 1080p60 HDMI capture ports, NDI input/output, professional audio inputs and outputs, GPU acceleration, and 16 GB of system memory, setting up your broadcast to go live has never been easier. Stream live church services, sporting events, classroom sessions, concerts, corporate communications, and more with confidence using Gear 3.

    Wirecast Gear Family
    Wirecast Gear 3 is a family of turnkey live video streaming and broadcast production appliances. Fully integrated into a single device, Gear 3 provides plug-in-and-go live-streaming and video production for up to five HD or 4K SDI, or four HDMI, sources. Live sports, news broadcasting, worship streaming, and live/ virtual event production is now available in one ready-to-go, convenient, rack-mountable unit.

    Every Gear 3 unit comes with an ultra-fast AMD Ryzen six-core processor, NVIDIA Quadro GPU for acceleration and encoding, Wirecast Pro software with Stock Media Library for video production and switching, and Switch Player to inspect and monitor the quality of your content. Built as a flexible Windows machine, Gear also supports common applications such as Microsoft Teams, Zoom, Adobe Creative Cloud, and more as the most comprehensive, configurable, and professional hardware appliance in its class. Elevate event production with ease and without stress when you take advantage of Telestream's top-of-the-line Wirecast Gear.

    • Features:

      • AMD Ryzen 5 6-core/12-thread processor
      • NVIDIA Quadro GPU for acceleration and encoding
      • 16GB System Memory
      • 9 USB 3.1 (incl. rear USB-C & dual front-mounted USB-A)
      • 1TB SATA3 SSD Storage Drive

    • Specifications:

      • Hardware Internal Configuration
      • CPU: AMD Ryzen 5 5600X 6-core/12-thread 4.6GHz (max)
      • Motherboard Chipset: AMD X570
      • GPU: NVIDIA Quadro T400 (HD models) / T1000 (4K models)
      • Memory: 16GB DDR4-3200
      • System Drive: 250GB NVMe M.2
      • Storage Drive: 1TB SATA3
      • USB: USB 3.1 Gen 2 (1x USB-C rear + 4x USB-A rear), USB 3.1 Gen 1 (2x USB-A front, 2x USB-A rear)
      • Network: 2xRJ-45 IEEE 802.3ab Gigabit Ethernet
      • Audio: 2-ch Line In/Out, Mic In/Out + Front Line Out / Mic In +
      • Ls/Rs/Lb/Rb/C/S

        Video Inputs and Outputs
      • Display Output - Wirecast Gear 3 HD HDMI: 3x Mini DisplayPort 1.4 920x1080 @ 60Hz max
      • Capture Input - Wirecast Gear 3 HD HDMI: 4x HDMI 1.4a (non-HDCP)

        Physical
      • Dimensions: 16.7 x 12 x 3.5", 2RU x 19" w/handles
      • Weight: 14.5-15.5 lb. (unit only)

        Power
      • Input Voltage: 90VAC-264VAC RMS Single Phase 47Hz-63Hz
      • Input Current: 8A @ 115VAC 60Hz RMS, 4A @ 230VAC 50Hz RMS, Single Phase
      • Input Connection: IEC 60320 C14 3-pin
      • Operating Temperature/Humidity: 32 - 104 F @ 20-80% (operating), -4 - 185 F @ 10-90% (storage)

    • Item Includes:

      • 1x Wirecast Gear 3 HD HDMI Professional Streaming Device
      • 1x Power cable
      • 1x Wireless keyboard
      • 1x Wireless mouse
      • 1x USB dongle for both the keyboard and mouse
      • AA batteries for both the keyboard and mouse

    • Warranty:

      • I Year

    • GTIN:

      0725272749730
