tvONE 1T-VS-668 Up Converter - CV/HD/PC/HDMI/Audio to HDMI/VGA

ITEM #: TV1-1T-VS-668 MFG #: 1T-VS-668

Primary Image
Free Shipping with $49 Minimum Order

Our Price:

$1,485.00

Availability: Ships Factory Direct, Typically in 3-10 Business Days
iAvailability Description Popup


    1T-VS-668 - Overview

    The 1T-VS-668 Video Scaler is a commercial switcher/scaler with versatile format conversion and multi-output routing capability. Fully scalable video inputs include HDMI, DVI (via DVI-to-HDMI adapter), analog RGB via HD-15 connectors, analog YPbPr or 480i/576i YUV Component via three RCA connectors and Composite Video. It handles I/O Resolutions up to 1080p and WUXGA. Both digital and analog audio processing are supported and audio delays of up to 150ms can be introduced to ensure lip sync. Eight analog stereo and inputs can be selected for embedding into the HDMI outputs. Separate coaxial digital and stereo audio outputs are also provided.

    • Features:

      • HDMI Max Res: WUXGA & 1080p
      • HDMI, RGB, YPbPr, YUV, CV In
      • Seamless switching (no sync loss)
      • Cross Conversion of Analog & Digital Audio
      • Audio Delay for Lip Sync Correction
      • HDCP Compliant
      • 3D Motion Adaptive De-Interlacing
      • Noise Reduction, 3D Comb Filter
      • 3:2 Pull-Down, 2:2 Pull-Down Recovery
      • Web GUI Control Interface
      • Infrared Remote Control
      • Locking DC Power Supply
      • Rack Mount Kit

    • Specifications:

      • Video Input
      • HDMI Input 3x via HDMI Connector
      • Analog RGBHV 3x via HD-15 Connector
      • YPbPr/YUV 1x via RCA Connectors
      • Composite Video 1x NTSC/PAL via RCA Connector
      • Audio Input
      • Analog Audio 2x via RCA (R,L), 6 via 3.5mm mini
      • Video Output
      • HDMI 2x via HDMI Connector
      • Analog RGBHV/YPbPr 1x via HD-15 Connector
      • Audio Output
      • HDMI Embedded 2x via HDMI Connector
      • Analog Stereo 1 via 3.5mm mini
      • Digital Audio(S/PDIF) 1x via RCA connector
      • Audio Delay Off, 40ms, 110ms, 150ms
      • Environmental
      • Operating Temperature 0° to +40° C (+32° to +104° F)
      • Operating Humidity 20% to 90%, Non-condensing
      • Storage Temperature -20° to +60° C (-4° to +140° F)
      • Storage Humidity 20% to 90%, Non-condensing

    • Item Includes:

      • 1x Power Adapter US, UK and Euro
      • 1x User Manual
      • 1x Rack Ear Set
      • 1x HD15 to YUV adapter cable
      • 1x IR Remote Control
      • 1x IR Extender
      • 1x Operations Manual
