Ubiquiti USW-PRO-XG-24-POE 24-Port Layer 3 Etherlighting PoE+++ Switch with 16x 10GbE / 8x 2.5GbE / 2x 25G SFP28 Ports

USW-PRO-XG-24-POE - Overview

Perfect for video-production, broadcast, or AV-over-IP installs!

• Features:

  • Wi-Fi 7 access points
  • IP video systems
  • Security cameras
  • High-performance workstations
  • NAS/SAN storage
  • Audio-over-IP and broadcast networks
  • Enterprise server infrastructure


• Specifications:

  • Switching Capacity: 460Gbps
  • Total Non-Blocking Throughput: 230Gbps
  • Forwarding Rate: 342Mpps
  • Supported VLANs: 1,000
  • MAC Address Table Size: 32,000
  • IPv4 Static Routes: 512
  • Packet Buffer Size: 8MB
  • Access Lists: IPv4 - 256, MAC - 256
  • PoE Ports - PoE+++: 24
  • Max. PoE Wattage per Port by PSE:
    - PoE: 15.4W
    - PoE+: 30W
    - PoE++: 60W
    - PoE+++: 90W
  • Max. Power Consumption:
    - 150W (Excluding PoE Output)
    - 870W (Including PoE Output)
  • Power Method:
    - 1x Universal input, 100-240V AC, 50/60 Hz
    - 1x USP RPS DC input
  • Power Input Method: AC input
  • Power Supply: AC/DC, internal, 870W
  • Supported Voltage Range: 100V - 240V AC
  • Management: Ethernet, AR
  • LCM Display: 1.3" touchscreen
